Comments must be received by October 24, 2014.

You may submit comments by any of the following methods:

Federal Rulemaking Portal: http://www.regulations.gov. Follow the on-line instructions for submitting comments.

Fax: 1-202-493-2251.

Mail: Docket Management System; U.S. Department of Transportation, Dockets Operations, M-30, Ground Floor, Room W12-140, 1200 New Jersey Avenue SE., Washington, DC 20590-0001.

Hand Delivery: To U.S. Department of Transportation, Dockets Operations, M-30, Ground Floor, Room W12-140, 1200 New Jersey Avenue SE., Washington, DC 20590-0001 between 9 a.m. and 5 p.m. Monday through Friday, except Federal holidays.

Instructions: Include the agency name and docket number PHMSA-2014-2013-0260 (HM-215M) or RIN 2137-AF05 for this rulemaking at the beginning of your comment. Note that all comments received will be posted without change to http://www.regulations.gov including any personal information provided. If sent by mail, comments must be submitted in duplicate. Persons wishing to receive confirmation of receipt of their comments must include a self-addressed stamped postcard.

Privacy Act: Anyone is able to search the electronic form of any written communications and comments received into any of our dockets by the name of the individual submitting the document (or signing the document, if submitted on behalf of an association, business, labor union, etc.). You may review DOT’s complete Privacy Act Statement in the Federal Register published on April 11, 2000 (65 FR 19477), or you may visit http://www.regulations.gov.

Docket: You may view the public docket through the Internet at http://www.regulations.gov or in person at the Docket Operations office at the above address (See ADDRESSES).

Steven Webb, Office of Hazardous Materials Standards or Vincent Babich, International Standards, telephone (202) 366-8553, Pipeline and Hazardous Materials Safety Administration, U.S. Department of Transportation, 1200 New Jersey Avenue SE., 2nd Floor, Washington, DC, 20590-0001.

PHMSA proposes to amend the HMR to maintain alignment with international regulations and standards by incorporating various amendments, including changes to proper shipping names, hazard classes, packing groups, special provisions, packaging authorizations, air transport quantity limitations, and vessel stowage requirements. This rulemaking project is part of our ongoing biennial process to harmonize the Hazardous Materials Regulations (HMR; 49 CFR parts 171 to 180) with international regulations and standards.

Federal law and policy strongly favor the harmonization of domestic and international standards for hazardous materials transportation. The Federal hazardous materials transportation law (Federal hazmat law; 49 U.S.C. 5101 et seq.) permits PHMSA to depart from international standards to promote safety or other overriding public interest, but otherwise requires PHMSA to align the HMR with international transport standards and requirements to the extent practicable (see 49 U.S.C. 5120).

Harmonization facilitates international trade by minimizing the costs and other burdens of complying with multiple or inconsistent safety requirements for transportation of hazardous materials to and from the United States and becomes increasingly important as the volume of hazardous materials transported in international commerce grows. By facilitating compliance, harmonization also tends to enhance safety for international movements, but only if the international standards provide an appropriate level of safety. PHMSA actively participates in the development of international standards for the transportation of hazardous materials, frequently advocating the adoption in international standards of particular HMR requirements.

When considering the adoption of international standards under the HMR, we review and consider each amendment on its own merit, on the basis of its overall impact on transportation safety, and the economic implications associated with its adoption into the HMR. Our goal is to harmonize without diminishing the level of safety currently provided by the HMR and without imposing undue burdens on the regulated community.

This NPRM proposes to amend the HMR to maintain alignment with various international standards. The following are some of the more noteworthy proposals in this NPRM:

• Incorporate Revised Standards: PHMSA proposes to incorporate by reference the newest versions of various international hazardous materials standards including the 2015-2016 International Civil Aviation Organization Technical Instructions for the Safe Transport of Dangerous Goods by Air (ICAO TI), Amendment 37-14 to the International Maritime Dangerous Goods Code (IMDG Code), the International Atomic Energy Agency (IAEA) Safety Standards for Protecting People and the Environment; Regulations for the Safe Transport of Radioactive Material, No. SSR-6, (IAEA Regulations), 2012 Edition, and the 18th Revised Edition of the United Nations Recommendations on the Transport of Dangerous Goods (UN Model Regulations). Additionally, we are proposing to update our incorporation by reference of the Canadian Transportation of Dangerous Goods Regulations to include Amendment 8 (SOR/2011-239) published November 9, 2011; Amendment 9 (SOR/2011-60) published March 16, 2011; Amendment 10 (SOR/2011-210) published October 12, 2011; and Amendment 11 (SOR/2012-245) published November 9, 2012. Finally, in this NPRM, PHMSA is proposing the adoption of updated International Standards Organization (ISO) standards.
• Revise HMT Entries: In this NPRM, PHMSA proposes amendments to the § 172.101 Hazardous Materials Table (HMT) to add, revise, or remove certain proper shipping names, hazard classes, packing groups, special provisions, packaging authorizations, bulk packaging requirements, passenger and cargo aircraft maximum quantity limits. The proposed changes to the HMT mirror recent changes in the Dangerous Goods list of the 18th Revised Edition of the UN Model Regulations, the IMDG Code, and the ICAO TI.
• Provide Exceptions for Marine Pollutants: PHMSA is proposing an exception from the HMR for marine pollutants up to 5 l (1.3 gal) for liquids or 5 kg (11 lbs.) for solids when these materials are packaged in accordance with the general packaging requirements of §§ 173.24 and 173.24a. The proposed amendment would exempt small packages of hazardous material from the HMR that are regulated only because of the presence of one or more marine pollutants. Materials in these quantities pose a low risk in transport and this proposal simplifies the current exceptions for marine pollutants and reduces impediments to multi-modal transport of these goods. The proposed changes to the HMT mirror recent changes in the Dangerous Goods list of the 18th Revised Edition of the UN Model Regulations, the IMDG Code, and the ICAO TI.
• Modification of the Marine Pollutant List: PHMSA is proposing to modify the list of marine pollutants in Appendix B to 172.101. The HMR maintain a list as the basis for regulating substances toxic to the aquatic environment and allow use of the criteria in the IMDG Code if a listed material does not meet the criteria for a marine pollutant. PHMSA periodically updates its list based on changes to the IMDG Code and evaluation of listed materials.
• Clarify Hazard Communication Size Requirements: PHMSA is proposing to add minimum sizes for the OVERPACK and SALVAGE markings. These markings would be characters at least 12 mm (.47 inches) high. There is no minimum size for these marks currently in the HMR, and the information is not always readily visible. Further, the HMR already prescribe specific size requirements for the “UN” or “NA” markings and package specification markings. This proposal is a logical extension of existing requirements. To offset any increased cost associated with the proposed size requirements, PHMSA will propose to permit a permanently marked salvage package or overpack to remain in service with its existing marks regardless of whether the identification number markings meet the minimum size requirements.
• Revise Vessel Stowage Requirements: PHMSA is proposing to revise and add vessel stowage codes listed in column 10B of the HMT and segregation requirements in § 176.83 consistent with the IMDG Code. These changes would harmonize the HMR with the IMDG Code and would provide additional guidance on the loading and stowage of various materials. Additionally, we propose to increase the required segregation distances between Division 4.3 dangerous when wet material (i.e. materials liable to give off a flammable or toxic gas in contact with water) and Class 3 flammable liquids and Division 2.1 flammable gases.
• Addition of Entries for Adsorbed Gases in the Hazardous Materials Table: Consistent with amendments adopted into the UN Model Regulations, PHMSA is proposing to revise the Hazardous Materials Table (HMT) in § 172.101 to include seventeen new entries for adsorbed gases. Additionally we propose to add into the HMR a definition for adsorbed gas, authorized packagings, and safety requirements including but not limited to quantity limitations and filling limits.
• Harmonized Requirements for Lithium Batteries: PHMSA proposes harmonization with the latest version of the ICAO Technical Instructions to ensure that the information currently authorized by the HMR to be provided by means of an alternative document be included on a shipping paper for batteries transported under the provisions of 49 CFR 173.185(c)(4)(v)—equivalent to Section IB of ICAO Packing Instructions 965 and 968. PHMSA also proposes to harmonize with the latest version of the ICAO Technical Instructions by requiring a “CARGO AIRCRAFT ONLY” label on packages containing small lithium metal batteries not packed in or with equipment.
• Definition of Non-Bulk Packaging: PHMSA proposes to revise the HMR definition of non-bulk packaging by adding a new paragraph (4) to include bags and boxes conforming to the applicable requirements for specification packagings in subpart L of part 178 of this subchapter, if they have a maximum net mass of 400 kg (882 pounds) or less. The UN Model regulations were revised to remove the volumetric limit for certain packaging types considered in Part 6 of the UN Model Regulations that would be considered non-bulk packagings under the HMR. This change was based on recognition by the UN Transport of Dangerous Goods Sub-Committee that there are packagings suitable for the transportation of high volume, low mass materials (e.g., airbags).

If the amendments in this proposed rule are not adopted in the HMR by January 1, 2015, the date most of the international standards above take effect, U.S. companies, including numerous small entities competing in foreign markets, will be at an economic disadvantage. These companies will be forced to comply with a dual system of regulations. The amendments proposed in this rulemaking are intended to avoid this result.

If adopted in a final rule, the amendments proposed in this NPRM will result in minimal burdens on the regulated community. The benefits resulting from the adoption of the amendments include enhanced transportation safety resulting from the consistency of domestic and international hazard communication and continued access to foreign markets by U.S. manufacturers of hazardous materials. The majority of amendments in this NPRM should result in cost savings and ease the regulatory compliance burden for shippers engaged in domestic and international commerce, including trans-border shipments within North America.

PHMSA solicits comments on the need for these amendments and others proposed in this NPRM. Specifically, PHMSA requests comments on the benefits and costs of international harmonization, including the impact on safety and any other relevant concerns regarding the amendments proposed in this NPRM. In addition, PHMSA solicits comment from the regulated community regarding approaches to reducing the costs of this rule while maintaining or increasing the benefits. In its preliminary analysis, PHMSA concluded that the aggregate benefits justify the aggregate costs as a result of the amendments proposed in this NPRM. Nonetheless, PHMSA solicits public comment on specific changes (for example, greater flexibility with regard to a particular amendment) that might improve the rule.

In a final rule published December 21, 1990 (Docket HM-181; 55 FR 52402), the Research and Special Programs Administration (RSPA), the predecessor agency to PHMSA, comprehensively revised the HMR to harmonize U.S. hazardous materials transportation requirements with the UN Model Regulations. The UN Model Regulations constitute a set of recommendations issued by the United Nations Subcommittee of Experts (UNSCOE) on the Transport of Dangerous Goods and the Globally Harmonized System of Classification and Labelling of Chemicals (GHS). The UN Model Regulations are amended and updated biennially by the UNSCOE and serve as the basis for national, regional, and international modal regulations, including the IMDG Code and the ICAO TI.

Since publication of the 1990 rule, PHMSA has issued ten additional international harmonization rulemakings under Dockets: HM-215A [59 FR 67390]; HM-215B [62 FR 24690]; HM-215C [64 FR 10742]; HM-215D [66 FR 33316]; HM-215E [68 FR 44992]; HM-215G [69 FR 76044]; HM-215I [71 FR 78595]; HM-215J [74 FR 2200]; HM-215K [76 FR 3308]; and HM-215L [78 FR 987]. These rulemakings were based on biennial updates of the UN Model Regulations, the IMDG Code, and the ICAO TI.

Federal law and policy strongly favor the harmonization of domestic and international standards for hazardous materials transportation. The Federal hazardous materials transportation law (Federal hazmat law; 49 U.S.C. 5101 et seq.) directs PHMSA to participate in relevant international standard-setting bodies and encourages alignment of the HMR with international transport standards to the extent practicable while recognizing that deviations may at times be necessary to ensure safety or be consistent with the public interest (see 49 U.S.C. 5120). Harmonization facilitates international trade by minimizing the costs and other burdens of complying with multiple or inconsistent safety requirements for transportation of hazardous materials. Harmonization has also become increasingly important as the volume of hazardous materials transported in international commerce grows. By facilitating compliance, harmonization enhances safety. PHMSA actively participates in relevant international standard-setting bodies and promotes the adoption of standards consistent with the high safety standards set by the HMR.

When considering alignment of the HMR with international standards, we review and evaluate each amendment on its own merit, on the basis of its overall impact on transportation safety, and the on the basis of the economic implications associated with its adoption into the HMR. Our goal is to harmonize without diminishing the level of safety currently provided by the HMR or imposing undue burdens on the regulated community.

Based on this review and evaluation, in this NPRM PHMSA is proposing to revise the HMR to incorporate changes from the 18th Revised Edition of the UN Model Regulations, Amendment 37-14 to the IMDG Code, and the 2015-2016 Edition of the ICAO Technical Instructions, which become effective January 1, 2015 (The IMDG Code is effective January 1, 2015; however, the previous amendment may continue to be used until January 1, 2016).

In addition, PHMSA proposes to incorporate by reference the newest editions of various international standards. These standards incorporated by reference are authorized for use, under specific circumstances, in Subpart C of Part 171 of the HMR. This proposed rule is necessary to incorporate revisions to the international standards and, if adopted in the HMR, will be effective January 1, 2015.

Possible Interim Final Rule

If the changes in this proposed rule are not adopted by January 1, 2015, U.S. companies, including numerous small entities competing in foreign markets, would be at an economic disadvantage because these companies would be forced to comply with a dual system of regulations (specifically, the U.S. HMR, UN Model Regulations, and ICAO Technical Instructions). As previously noted, the changes to the international standards will take effect on January 1, 2015. Therefore, it is essential that a final rule incorporating these standards by reference be published no later than December 31, 2014 with an effective date of January 1, 2015. To this end, if it appears a final rule under this docket will not be published prior to January 1, 2015, PHMSA will publish a bridging document in the form of an interim final rule to amend the HMR by incorporating the 18th Revised Edition of the UN Recommendations and the 2015-2016 Edition of the ICAO Technical Instructions.

With regard to Amendment 37-14 of the IMDG Code, the International Maritime Organization approved an implementation date of January 1, 2016. The current edition of the IMDG Code (Amendment 36-12) remains in effect through 2015 and, therefore, the newest version of the IMDG Code will not be included in any bridging document. The proposed incorporation by reference of the newest edition of the IMDG Code and all other changes proposed in this NPRM would be addressed in a subsequent final rule also under this Docket, PHMSA-2013-0260 (HM-215M). Accordingly, any interim final rule will only incorporate by reference editions of the international standards that become effective on January 1, 2015.

In addition to various other revisions to the HMR, in this NPRM, PHMSA is proposing the following amendments to harmonize the HMR with the most recent revisions to the UN Model Regulations, ICAO TI, and the IMDG Code:

Hazardous Materials Table (HMT)

In this NPRM, PHMSA proposes amendments to the HMT to add, revise, or remove certain proper shipping names, hazard classes, packing groups, special provisions, packaging authorizations, bulk packaging requirements, vessel stowage and segregation requirements, and passenger and cargo aircraft maximum quantity limits.

Incorporation by Reference

In this NPRM, PHMSA proposes to incorporate by reference the latest editions of various international transport standards including the 2015-2016 Edition of the ICAO Technical Instructions, Amendment 37-14 of the IMDG Code, and the 18th Revised Edition of the UN Model Regulations. Additionally, we are proposing to update our incorporation by reference of the Canadian Transportation of Dangerous Goods Regulations to include Amendment 8 (SOR/2011-239) published November 9, 2011; Amendment 9 (SOR/2011-60) published March 16, 2011; Amendment 10 (SOR/2011-210) published October 12, 2011; and Amendment 11 (SOR/2012-245) published November 9, 2012. This incorporation by reference augments the broad reciprocity provided in § 171.12 where the HMR allow the use of the Canadian TDG Regulations under certain conditions when transporting hazardous materials to or from Canada by highway or rail. Finally, PHMSA is proposing the incorporation by reference of new and updated International Standards Organization (ISO) standards.

Petitions for Rulemaking: In this NPRM, PHMSA is addressing three petitions for rulemaking:

Alignment of the HMR With the ICAO TI To Remove the Segregation Requirements in § 175.630 (P-1631)

In a petition for rulemaking (P-1631), UPS, Inc. requests that PHMSA align with the ICAO TI by removing the § 175.630 provisions requiring Division 6.1 and 6.2 packages to be segregated from materials marked as or known to be a foodstuff, feed, or any other edible material intended for consumption by humans or animals.

Section 175.630 imposes special segregation requirements for Division 6.1 (toxic) material and Division 6.2 (infectious substance) materials when transported by aircraft. Paragraph (a) requires that a package required to bear a POISON, POISON INHALATION HAZARD, or INFECTIOUS SUBSTANCE label may not be carried in the same compartment of an aircraft with material which is marked as or known to be a foodstuff, feed, or any other edible material intended for consumption by humans or animals unless:

(1) The Division 6.1 or Division 6.2 material and the foodstuff, feed, or other edible material are loaded in separate unit load devices which, when stowed on the aircraft, are not adjacent to each other; or

(2) The Division 6.1 or Division 6.2 material are loaded in one closed unit load device and the foodstuff, feed or other material is loaded in another closed unit load device.

The petitioner notes that during 2012-2013 biennium, the ICAO Dangerous Goods Panel (DGP) determined that the high quality of packaging for Division 6.1 and 6.2 material required by the ICAO TI justified removal of the segregation requirements applied to Division 6.1 or Division 6.2 material and foodstuffs. The petitioner states that the alignment of the HMR with the ICAO TI on the matter of operator requirements is of great value for aircraft operators. In addition, the petitioner states that this amendment has the potential to introduce efficiencies for air carriers, including UPS. In this context, with the deletion of ICAO TI Part 7, Section 2.9, the petitioner recommends and requests that PHMSA remove the corresponding requirements of § 175.630.

PHMSA is in agreement with the petitioner and in this NPRM, is proposing to delete the special segregation requirements for Division 6.1 and Division 6.2 material. This action would harmonize the HMR with recent amendments that will appear in the 2015-2016 Edition of the ICAO TI. These segregation requirements are no longer necessary, and we propose to harmonize with ICAO because of: (1) The relative rarity of releases of toxic and infectious substances; (2) the small quantities released when a spill actually occurs; (3) the robust nature of combination packagings used for toxic and infectious substances; (4) the acceptance checks required by operators prior to loading hazardous materials aboard aircraft; (5) the lack of evidence of contamination of other packages by a release of toxic or infectious substances; and (6) the coverage by the hazard communication system already in place in the event of a release.

Passenger Notification Programs for Tickets Issued by Phone (P-1623)

In a petition for rulemaking (P-1623), the Council on Safe Transportation of Hazardous Articles (COSTHA) requests that PHMSA remove the applicability of passenger notifications in § 175.25(b) to telephone transactions.

In a final rule published January 19, 2011 under Docket No. PHMSA-2009-0126 (HM-215K); 76 FR 3308, PHMSA aligned with the ICAO TI by adding new requirements for certain information to be presented to passengers regarding what hazardous materials they may check-in or carry-on a flight. This information is to be provided at points of ticket sale and at automated or remote passenger check-in. On March 7, 2013, PHMSA received a request for a letter of interpretation (Reference 13-00058) from COSTHA pointing out that the January 19, 2011 final rule in § 175.25 (b) includes the word “phone” which is not in Part 7; 5.1.1 of the ICAO TI, nor is it part of the current scope of passenger notification programs. COSTHA requested clarification as to whether or not PHMSA intended the § 175.25(b) requirement to be applicable to passenger notification by telephone. In the July 11, 2013 response, PHMSA stated that § 175.25(b) explicitly references purchase by telephone as a means of purchasing a ticket remotely. Therefore, as written, the § 175.25(b) passenger notification and acknowledgement requirements apply when purchasing a ticket by telephone and this is generally consistent with Part 7; 5.1.1 of the ICAO TI. This petition was submitted in response to the letter of interpretation issued by PHMSA on July 11, 2013 (Reference 13-0058).

In its petition, COSTHA states that they strongly disagree with PHMSA’s position that inclusion of the term “phone” in § 175.25(b) is “generally consistent” with the language adopted in Part 7; 5.1.1 of the ICAO TI, and that PHMSA has not fully recognized or accounted for the significant costs such an interpretation would impose on industry and the competitive disadvantage that would result for U.S. passenger air carriers. The petitioner notes that the issue of ticket purchase and check-in on line was discussed within a working group of the ICAO DGP (May 2009) and that the discussion only pertained to electronic transactions, not telephone transactions. The report from the meeting specifically states “when purchasing tickets or checking in electronically.” The report includes comments from DGP members questioning who would enforce the requirement against internet-based travel agencies. There is no reference to ticket purchases made via telephone. At the 22nd meeting of the ICAO DGP (October 2009), ICAO adopted modifications to Part 7; 5.1 to bolster communication to passengers who purchase tickets or check-in electronically. Paragraph 2.8.2.1 from the DGP 22 report states:

The petitioner notes that DGP 23 report contains the first reference to the use of telephones, and in this case it is in reference to passenger check-ins, not ticket purchase. Further revisions to the ICAO TI text resulted in mandatory requirements. However, the context of these discussions was again regarding electronic transactions, not via the telephone. The petitioner states based on the information contained in the ICAO reports that it was not the intention of ICAO to require extensive hazard communication during telephonic ticket purchases.

The petitioner states that by extending the application of notification to passengers to telephonic ticket purchases, PHMSA is imposing significant training and implementation costs on industry and that these costs may not have been fully considered. In the petition, COSTHA includes estimated costs from three member air carriers for providing passenger notification via telephonic communication. One carrier estimated an annual cost increase of $17 million, another $750,000, and the third $450,000 a year for every second added to talk time. These figures do not include employee training costs. In addition, these three airlines provided data that between 3% and 5.1% of tickets are purchased over the phone. The petitioner points out that the vast majority of tickets are purchased on-line, and when purchased in this manner, passengers are notified about hazardous materials at the time of purchase, during check-in, and again via an announcement at the gate. The petitioner states that extending these requirements to telephone transactions will significantly increase costs to industry while reaching only 5% of passengers purchasing tickets.

In this NPRM, PHMSA is proposing to grant this petition by adopting into the HMR the revisions made to the passenger notification provisions of Part 7;5.1 of the ICAO TI adopted at the 24th meeting of ICAO DGP (October 2013). Paragraph 2.7.3.1 from the DGP 24 report states:

Specifically, PHMSA is proposing to revise § 175.25(b) for consistency with the ICAO TI to clarify that for ticket purchases the hazardous materials notification must be presented at the point of ticket purchase or, if this not practical, made available in another manner to passengers prior to the check-in process. This will allow an operator to provide the hazardous materials notification verbally, with the ticket or ticket receipt, or using another equally suitable method. In addition, PHMSA is proposing to remove the words “regardless if the process is completed remotely (e.g., via the Internet and Phone) or when completed at the airport, with or without assistance from another person (e.g., automated check in facility)” as examples of ticket purchases to fully harmonize § 175.25(b) with the ICAO TI, and to clarify that the hazardous materials notification must be given with every ticket purchase. Finally, it is proposed to insert the words “provided via the internet” into the second sentence of § 175.25(b) to clarify that passenger acknowledgement is only required when the ticket is purchased through the internet without assistance from another person. All of these proposed changes taken together will address the COSTHA petition and bring the HMR into full alignment with the ICAO TI.

Compliance Date Extension for Passenger Notification Programs (P-1633)

In a petition for rulemaking (P-1633), COSTHA requests that PHMSA extend the transitional compliance date for “hazardous materials notifications to passengers at time of ticket purchase,” which was adopted in a January 19, 2011 final rule (Docket No. PHMSA-2009-0126 (HM-215K); 76 FR 3308) and extended to January 1, 2015 in a final rule published January 7, 2013 (Docket No. PHMSA-2009-0126 (HM-215K); 78 FR 1108). Specifically, COSTHA requests the current compliance date for passenger notifications requirements in § 175.25 be extended from January 1, 2015 until 12 months from the effective date of the HM-215M final rule publication, or January 1, 2016, whichever is later.

The petitioner states on April 30, 2013, the Federal Aviation Administration (FAA) chartered an Aviation Rulemaking Committee (ARC) on Passenger Notification of Hazardous Materials Regulations with a mission to develop consistent and effective messages for disseminating hazardous materials information to passengers and provide air carriers additional clarity to ensure regulatory compliance. The FAA timeline for the ARC and publication of the draft advisory circular was developed to provide air carriers eight months to implement the recommendations, employee training, program changes and to make necessary technology updates. Due to additional amendments to the passenger notification requirements of the ICAO TI the implementation and subsequent consideration for harmonization under this proposed rule the timeline established by the FAA was delayed. Given this delay, air carriers will not be provided sufficient time to implement changes necessary to comply with the modified § 175.25.

In this NPRM, PHMSA is proposing to revise § 175.25(b) for consistency with recent amendments to the ICAO TI to clarify that for ticket purchases made via the telephone, the hazardous materials notification must be provided to the passenger but can be done so using any suitable method prior to the check-in. Due to this revision, the extension requested in this petition is unnecessary. The requirement for air carrier reservation agents to verbally provide passenger notification at the time of purchase by telephone was the basis for the effective date extension granted in the January 7, 2013 final rule (HM-215K). By removing the telephonic acknowledgement requirement, the previous effective date of January 1, 2015 will be waived as of publication. Other than the telephonic acknowledgement requirement, PHMSA is unaware of any additional new requirement imposed under HM-215K that has posed difficulty in implementation that would merit providing additional compliance date relief. Further, proposed amendments to § 175.25 in this rulemaking are eligible for the one year delayed compliance.

This NPRM proposes changes to the HMR based on amendments adopted in the 18th Revised Edition of the UN Model Regulations, the 2015-2016 Edition of the ICAO Technical Instructions, and Amendment 37-14 to the IMDG Code. We are not, however, proposing to adopt all the amendments made to the various international standards into the HMR.

In many cases, amendments to the international recommendations and regulations have not been adopted because the framework or structure of the HMR makes adoption unnecessary. In other cases, we have addressed, or will address, the amendments in separate rulemaking proceedings. If we have inadvertently omitted an amendment in this NPRM, we will attempt to include the omission in the final rule. However, our ability to make changes in a final rule is limited by requirements of the Administrative Procedure Act (5 U.S.C. 553). In some instances, we can adopt a provision inadvertently omitted in the NPRM if it is clearly within the scope of changes proposed in the notice. Otherwise, in order to provide opportunity for notice and comment, the change must first be proposed in an NPRM.

One of the goals of this rulemaking is to continue to maintain consistency between the HMR and the international requirements. We are not striving to make the HMR identical to the international regulations but rather to remove or avoid potential barriers to international transportation.

The following is a list of significant amendments to the international regulations that we are not proposing to adopt in this NPRM, with a brief explanation of why the amendment was not included:

Damaged, Defective, and Waste Lithium Batteries

The 18th Revised Edition of the UN Model Regulations adopted transportation provisions for damaged, defective, and waste lithium batteries. In this NPRM, PHMSA is not proposing to adopt changes to the domestic requirements for the treatment of these lithium batteries, as we believe existing HMR requirements sufficiently address shipments of this nature.

Dimensions on Hazard Communication Examples

The 18th Revised Edition of the UN Model Regulations adopted modifications to example figures of markings, labels, and placards to note minimum dimensions for the appropriate hazard communication example pictograms. In this NPRM, PHMSA is not proposing to adopt the changes to example markings, labels, and placards found in the HMR. We believe the addition of dimensions to the example pictograms does not add significant value because these dimensions are described in the text of the HMR. These amendments to the international recommendations and regulations are not being adopted because the regulatory text associated with the various figures in the HMR depicting package markings, labels and placards adequately describes the item without adding minimum dimensions to the example figures.

Flash Composition

The 18th Revised Edition of the UN Model Regulations amended a note before the default fireworks classification table in 2.1.3.5.5. This amendment changed the criteria used in the meaning of “flash composition” from 8 ms for .5 g of pyrotechnic substance in the HSL Flash Composition Test in Appendix 7 of the Manual of Tests and Criteria, to 6 ms for .5 g of pyrotechnic substance. In this NPRM, PHMSA is not adopting this change as work on this test is ongoing.

Radioactive Materials Transportation Requirements

The 18th Revised Edition of the UN Model Regulations, the 2015-2016 Edition of the ICAO Technical Instructions, and Amendment 37-14 to the IMDG Code amended various radioactive transportation requirements to harmonize their regulations with the International Atomic Energy Agency (IAEA) Safety Standards for Protecting People and the Environment; Regulations for the Safe Transport of Radioactive Material, No. SSR-6. While PHMSA is proposing to incorporate by reference this document (see § 171.7) and adopt the new proper shipping name and associated shipping requirements for UN 3507, Uranium hexafluoride, radioactive material, excepted package, we are not proposing to harmonize the HMR with the remainder of the changes made by the various international regulations in this NPRM. Any further domestic radioactive harmonization issues will be addressed in a future rulemaking in conjunction with the Nuclear Regulatory Commission.

Discarded Packages

The 18th Revised Edition of the UN Model Regulations adopted a new proper shipping name and UN number for Packaging discarded, empty, uncleaned, UN 3509. This new proper shipping name was brought in to allow, with competent authority approval, packagings, large packagings or intermediate bulk containers, or parts thereof, which have contained hazardous materials, other than radioactive material to be transported for disposal, recycling or recovery of their material, other than reconditioning, repair, routine maintenance, remanufacturing or reuse, and which have been emptied to the extent that only residues of dangerous goods adhering to the packaging parts are present when they are presented for transport. This change was made primarily to address European land transport of packages that are no longer within appropriate package specifications. The ICAO DGP did not incorporate this entry into the ICAO TI dangerous goods list, and the IMDG Code has adopted very limited allowance for the use of this entry on short sea voyages.

PHMSA is not proposing to include a hazardous materials table entry for UN 3509 Packaging discarded, empty, uncleaned. We believe that the shipment of empty uncleaned packaging is adequately addressed by HMR under existing empty packaging provisions in § 173.29 and additional sections. Use of this description in the UN Model Regulations requires authorization by the competent authority, which can still be obtained from PHMSA via a special permit.

Used Medical Devices

In the 2015-2016 Edition of the ICAO TI a note was added to an exception for used medical devices which excepts medical devices or equipment that have been drained of free liquid to the extent practicable; and clarifying that any capability requirement in the ICAO TI can be determined through testing a sample package as prepared for transport, or through alternative means such as non-destructive testing, engineering analysis, testing with an article of similar mass and size, or other equivalent means. PHMSA is not making any corresponding amendments to § 173.134, as we believe the existing HMR satisfactorily addresses the hazards presented by used medical devices in transportation.

Coolants, Conditioners, and Asphyxiates

The 18th Revised Edition of the UN Model Regulations contains various editorial amendments applicable to packages and cargo transport units containing substances presenting a risk of asphyxiation when used for cooling or conditioning purposes. PHMSA did not adopt requirements for these shipments instituted in the 17th Revised Edition of the UN Model Regulations, and will not be adopting any of the editorial amendments incorporated into the 18th UN Model Regulations either. PHMSA believes that the current requirements for shipments of dry ice and other potential coolants adequately address the hazards associated with the use of these hazardous materials as coolants or conditioners.

Gas Cartridge and Fuel Cell Testing

The 18th Revised Edition of the UN Model Regulations was amended to authorize alternatives to the water bath test for gas cartridges and fuel cells. PHMSA believes that the current requirements provided by the HMR for testing these items adequately address the hazards associated with their use.

The following is a section-by-section review of the amendments proposed in this NPRM:

Part 171

Section 171.4 prohibits the transportation of materials meeting the definition of a marine pollutant except in accordance with HMR requirements. Paragraph (c) provides that marine pollutants transported in non-bulk packagings are excepted from the HMR unless the transportation is by vessel. In this NPRM, PHMSA proposes a new exception from the HMR for marine pollutants up to 5 l (1.3 gallons) for liquids or 5 kg (11 lbs) for solids when these materials are packaged in accordance with the general packaging requirements of §§ 173.24 and 173.24a. This proposed amendment, applicable to all modes, would exempt small packages of hazardous material from the HMR that are regulated only because of the presence of one or more marine pollutants. Materials in these quantities pose a low risk in transport and this proposal simplifies the current exceptions for marine pollutants and reduces impediments to multi-modal transport of these goods.

Section 171.7

The “National Technology Transfer and Advancement Act of 1996” directs agencies to use voluntary consensus standards. According to the Office of Management and Budget (OMB), Circular A-119, “Federal Participation in the Development and Use of Voluntary Consensus Standards and in Conformity Assessment Activities,” government agencies must use voluntary consensus standards wherever practical in the development of regulations. Agency adoption of industry standards promotes productivity and efficiency in government and industry, expands opportunities for international trade, conserves resources, improves health and safety, and protects the environment.

To these ends, PHMSA actively participates in the development and updating of consensus standards through representation on more than 20 consensus standard bodies. PHMSA regularly reviews updated consensus standards and considers their merit for inclusion in the HMR.

Section 171.7 provides a listing of all standards incorporated by reference into the HMR. For this rulemaking, we evaluated updated international consensus standards pertaining to proper shipping names, hazard classes, packing groups, special provisions, packaging authorizations, air transport quantity limitations, and vessel stowage requirements and determined that the revised standards provide an enhanced level of safety without imposing significant compliance burdens. These standards have a well-established and documented safety history and their adoption will maintain the high safety standard currently achieved under the HMR. Therefore, we propose to update by adding and revising the incorporation by reference materials for the following organizations:

Paragraph (s)(1) which incorporates the International Atomic Energy Agency (IAEA) Regulations for the Safe Transport of Radioactive Material 1996 edition would be revised to incorporate the SSR-6 2012 Edition. To address concerns over domestic and international differences in the transport conditions applicable to shipments of excepted fissile materials, PHMSA is proposing to add additional requirements to § 171.23 to ensure domestic concerns are addressed. Please see the discussion in the Section-by-Section Review under § 171.23 for a summary of proposed changes.

Paragraph (t)(1) which incorporates the International Civil Aviation Organization Technical Instructions for the Safe Transport of Dangerous Goods by Air, 2013-2014 Edition would be revised to incorporate the 2014-2015 Edition.

Paragraph (v)(2), which incorporates the International Maritime Organization International Maritime Dangerous Goods Code, 2012 Edition, Incorporating Amendment 36-12, English Edition, Volumes 1 and 2, would be revised to incorporate the 2014 Edition, Amendment 37-14.

In paragraph (w) various International Organization for Standardization (ISO) entries which contain standards for the specifications, design, construction, testing and use of gas cylinders are proposed for incorporation by reference.

In paragraph (bb)(1), the Transport Canada, Transportation of Dangerous Goods Regulations, including Clear Language Amendments 1 through 7 sub-paragraphs (ix), (x), (xi), and (xii), would be added to include Amendment 8 (SOR/2011-239) which was published on November 9, 2011; Amendment 9 (SOR/2011-60) published March 16, 2011; Amendment 10 (SOR/2011-210) published October 12, 2011; and Amendment 11 (SOR/2012-245) published November 9, 2012 respectively. In the preamble of our January 7, 2013 final rule (HM215-L [78 FR 987]) we indicated we were adopting Amendments 8, 9 and 10 of the Transportation of Dangerous Goods Regulations, however this adoption inadvertently did not appear in the published regulatory text. To correct this oversight, we are again proposing the adoption of Amendments 8, 9 and 10, along with the proposed adoption of the most recent, Amendment 11.

Paragraph (dd)(1), the United Nations Recommendations on the Transport of Dangerous Goods—Model Regulations, 17th Revised Edition (2011), Volumes I and II, would be revised to incorporate the 18th Revised Edition (2013), Volumes I and II.

Paragraph (dd)(2), the United Nations Recommendations on the Transport of Dangerous Goods—Manual of Tests and Criteria, Fifth Revised Edition (2009), including Amendment 1 (2011), would be revised to reference § 171.24, and sub-paragraph (iii) would be added to incorporate Amendment 2 (2013).

Section 171.8

This section defines terms generally used throughout the HMR that have broad or multi-modal applicability. PHMSA is proposing to add the following terms:

Adsorbed gas: The proposed adoption of this term directs the reader to § 173.115 for the definition. See the § 173.115 entry of the Section-by-Section Review for a complete discussion of the proposed adoption of the definition of adsorbed gas.

Bundle of cylinders: Consistent with the ICAO TI, in this NPRM, PHMSA proposes to amend this definition to clarify that a “bundle of cylinders” is not permitted for air transport.

Large salvage packaging: Consistent with the UN Model Regulations, in this NPRM, PHMSA proposes to define a large salvage packaging. A large salvage packaging is a special packaging into which damaged, defective or leaking hazardous materials packages, or hazardous materials that have spilled or leaked are placed for the purpose of transport for recovery or disposal. The general requirements for a large salvage packaging are consistent with the existing requirements for a “large packaging.” Large salvage packagings are not authorized for air transport.

Neutron radiation detector: Consistent with the UN Model Regulations, in this NPRM, PHMSA proposes to define a neutron radiation detector. A neutron radiation detector is a device that detects neutron radiation. In such a device, a gas may be contained in a hermetically sealed electron tube transducer that converts neutron radiation into a measurable electric signal.

Non-bulk packaging: The UN Model regulations were revised to remove the volumetric limit for certain packaging types considered in Part 6 of the UN Model Regulations that would be considered non-bulk packagings under the HMR. This was based on recognition by the UN Transport of Dangerous Goods Sub-Committee that there are packagings suitable for the transportation of high volume, low mass materials (e.g., airbags) where the capacity of a box may exceed 450 liters (119 gallons) while the net mass of the box is less than 400 kg (882 pounds). Absent a corresponding amendment to the HMR, U.S. manufacturers and shippers would be placed at a competitive disadvantage by not being authorized to use the same packaging configurations other than as authorized for use by Part 171 Subpart C (use of international transport standards and regulations). Therefore, to maintain consistency with the UN Model Regulations, and to authorize the use of these packaging configurations for domestic transport, PHMSA proposes to revise the HMR definition of non-bulk packaging by adding a new paragraph (4) to include bags and boxes conforming to the applicable requirements for specification packagings in subpart L of part 178 of this subchapter, if they have a maximum net mass of 400 kg (882 pounds) or less. Based on our review of the UN Model Regulations, these are the only packagings affected by the UN amendment as only bags and boxes are authorized by specification to exceed 450 liters capacity.

Radiation Detection System: Consistent with the UN Model Regulations, in this NPRM, PHMSA proposes to define a radiation detection system. A radiation detection system is an apparatus that contains radiation detectors as components.

Section 171.23

Section 171.23 prescribes requirements for specific materials and packagings transported under various international standards. Section 171.22(b)(2) requires shipments made in accordance with an authorized international standard or regulation to conform to all applicable requirements of Subpart C of Part 171.

Paragraph (b)(2) of this section provides the requirement that the shipping paper description of items such as air bag inflators, air bag modules, and seat-belt pretensioners conform to the requirements in § 173.166(c). Consistent with the UN Model Regulations, in this NPRM, PHMSA proposes to revise the proper shipping name of these items to read “Safety device,” with the addition of the term “pyromechanical device” being included as a “Safety device.” Paragraph (b)(2) is being revised to reference the new proper shipping name, “Safety device” and the new term “pyromechanical device.” As a consequence of the addition of the proper shipping name “Safety devices, pyrotechnic,” and special provision 161 being removed, paragraph (b)(2)(ii) is removed and reserved.

Paragraph (11) of this section prescribes additional requirements for shipments of radioactive materials made under authorized international standards or regulations. In this NPRM, PHMSA is proposing to incorporate by reference the 2012 IAEA SSR-6 regulations to allow shipments to be offered for transportation or transported under the most recent IAEA regulations. Several changes to the definition of excepted fissile materials and the requirements for its transport were adopted by the IAEA. Under their respective statutory authorities, DOT and the Nuclear Regulatory Commission (NRC) jointly regulate the transportation of radioactive materials to, from, and within the United States. The NRC has not initiated any rulemaking activities to address changes made by the IAEA regarding the transportation of excepted fissile materials. In order to maintain uniform treatment for shippers of excepted fissile materials, PHMSA is amending § 171.23 to require that shipments of excepted fissile materials offered in accordance with the IAEA SSR-6 regulations must also conform to the requirements of § 173.453.

Section 171.24

Section 171.24 details additional requirements for the use of the ICAO TI. In this NPRM, PHMSA is proposing to amend the marking requirement for packages containing primary lithium batteries and cells that meet the exceptions in paragraph (d)(1)(ii). Packages meeting these exceptions currently are required to be marked with an indication that they contain lithium batteries, and that these lithium batteries are forbidden for transport aboard passenger aircraft. PHMSA is proposing to allow the message that these batteries are forbidden for transport aboard passenger aircraft to be expressed through the current marking or by using a CARGO AIRCRAFT ONLY label as shown in § 172.448.

Section 171.25

Section 171.24 details additional requirements for the use of the IMDG Code. In this NPRM, PHMSA is proposing to amend the marking requirement for packages containing primary lithium batteries and cells that meet the exceptions in § 173.185(c) in paragraph (b)(3). Packages meeting these exceptions currently are required to be marked with an indication that they contain lithium batteries, and that these lithium batteries are forbidden for transport aboard passenger aircraft. PHMSA is proposing to allow the message that these batteries are forbidden for transport aboard passenger aircraft to be expressed through the current marking or by using a CARGO AIRCRAFT ONLY label as shown in § 172.448.

Part 172

Section 172.101

Section 172.101 provides instructions for using the Hazardous Materials Table (HMT) and the HMT itself. In this NPRM, PHMSA is proposing to revise the instructional text that precedes the HMT for paragraph (k) of this section.

Paragraph (k) of § 172.101 explains the purpose of column (10) of the HMT and prescribes the vessel stowage and segregation for specific entries in the HMT. Column (10) is divided into two columns: Column (10A) [Vessel stowage] specifies the authorized stowage locations on board cargo and passenger vessels and column (10B) [Other provisions] specifies special stowage and segregation provisions. PHMSA is proposing to amend this instructional text to note that the codes in column 10B address not only codes for stowage requirements, but also, in certain instances, handling requirements that need to be observed during loading of the hazardous materials. The IMO, in amendment 37-14 of the IMDG Code, has split their stowage and segregation column (16) in the dangerous goods list into two columns and assigned codes to the existing stowage, handling, and segregation text. The new first column (16a) in the IMDG Code is entitled stowage and handling, and the second column (16b) is titled segregation. PHMSA is proposing to maintain the HMR’s current column 10A and 10B system, with text in this section and § 176.84 indicating that handling/loading of hazardous materials is also covered by certain codes in column 10B. See Section 176.84 other requirements for stowage, cargo handling, and segregation for cargo vessels and passenger vessels for a detailed discussion of proposed changes.

Hazardous Materials Table (HMT)

In this NPRM, PHMSA is proposing to amend the HMT. Readers should review all changes for a complete understanding of the amendments. For purposes of the Government Printing Office’s typesetting procedures, proposed changes to the HMT appear under three sections of the Table, “remove,” “add,” and “revise.” Certain entries in the HMT, such as those with revisions to the proper shipping names, appear as a “remove” and “add.” Proposed amendments to the HMT include the following:

New HMT Entries

UN3507Uranium hexafluoride, radioactive material, excepted package, less than 0.1 kg per package, non-fissile or fissile-excepted

This new HMT entry addresses small quantities of uranium hexafluoride having corrosive properties by assigning the material to Class 8 with a subsidiary risk of Class 7 since this would be more consistent with the general rule of classification of radioactive material in limited quantities possessing other hazards per § 173.423. Shipments must comply with new special provision 369 and requirements found in § 173.420(d).

UN3508Capacitor, asymmetric with an energy storage capacity greater than 0.3Wh

This new HMT entry is intended to cover asymmetric capacitors with an energy storage capacity greater than 0.3 Wh. Asymmetric capacitors are assigned as a Class 9 miscellaneous hazardous.

UN3510Adsorbed gas, flammable, n.o.s.

UN3511Adsorbed gas, n.o.s.

UN3512Adsorbed gas, toxic, n.o.s.

UN3513Adsorbed gas, oxidizing, n.o.s.

UN3514Adsorbed gas, toxic, flammable, n.o.s.

UN3515Adsorbed gas, toxic, oxidizing, n.o.s.

UN3516Adsorbed gas, toxic, corrosive, n.o.s.

UN3517Adsorbed gas, toxic, flammable, corrosive, n.o.s.

UN3518Adsorbed gas, toxic, oxidizing, corrosive, n.o.s.

UN3519Boron trifluoride, adsorbed

UN3520Chlorine, adsorbed

UN3521Silicon tetrafluoride, adsorbed

UN3522Arsine, adsorbed

UN3523Germane, adsorbed

UN3524Phosphorus pentafluoride, adsorbed

UN3525Phosphine, adsorbed

UN3526Hydrogen selenide, adsorbed

The “Adsorbed gas” HMT entries are added to address shipments of gas, which when packaged for transport, are adsorbed onto a solid porous material in a pressure receptacle. Entries classified as Division 2.3 gases are forbidden for transport by aircraft.

Duplicate entries for UN0214 Trinitrobenzene, dry or wetted with less than 30 percent water, by mass currently exist in the HMT; while the UN1354 entry has been inadvertently overwritten by one of these UN0214 entries in an unidentified previous rulemaking. PHMSA is proposing to remove one of the duplicate UN0214 entries, and to reinsert the correct UN1354 entry.

During the course of reviewing Column 10B (Vessel stowage Other codes) for harmonization with changes made in the 37-14 IMDG Code, PHMSA noticed that the entry for UN3231 Self-reactive liquid type B, temperature controlled is not currently listed in the HMR. This is believed to be the result of an inadvertent deletion in an unidentified rulemaking. PHMSA is proposing to reinstate the HMT entry for UN3231.

Amendments to the Column (1) Symbols

Section 172.101(b) describes column (1) of the HMT and the associated symbols that may be indicated in the column. In accordance with § 172.101(b), the symbol “G” identifies proper shipping names for which one or more technical names of the hazardous material must be entered in parentheses in association with the basic description on a shipping paper. The symbol “I” indicates these proper shipping names are appropriate for describing materials in international transportation, but that an alternate proper shipping name may be selected when only domestic transportation is involved.

In this NPRM PHMSA is proposing to add international proper shipping names for “Asbestos, amphibole (amosite, tremolite, actinolite, anthophyllite, crocidolite)” and “Asbestos, chrysotile”, and remove shipping descriptions for Blue, Brown, and White Asbestos. These new international proper shipping names for “Asbestos, amphibole” and “Asbestos, chrysotile” are proposed to have an “I” assigned in column one. PHMSA is also proposing to assign a “G” to the “Asbestos, amphibole” entry. The “G” indicates that the technical name(s) of the hazardous material must be entered in parentheses, in association with the basic description. In the case of this proposed proper shipping name, the technical name shown should be selected from the list of five different minerals (amosite, tremolite, actinolite, anthophyllite, crocidolite) indicated in italics after the proper shipping name. See the amendments to column (2) of the HMT for additional discussion regarding the revision of the proper shipping names for these entries.

Amendments to the Column (2) Hazardous Materials Descriptions and Proper Shipping Names

Section 172.101(c) describes column (2) of the HMT and the requirements for hazardous materials descriptions and proper shipping names.

The proper shipping name for “UN0222, Ammonium nitrate, with more than 0.2 percent combustible substances, including any organic substance calculated as carbon, to the exclusion of any other added substance” is amended by removing the italicized text and placing the text into the new special provision 370.

The proper shipping name for “UN1942, Ammonium nitrate, with not more than 0.2% combustible materials, including any organic substance, calculated as carbon to the exclusion of any other added substance” is amended by replacing the word “materials” in italicized text with “substances” and the comma following “substance” is placed after the word “carbon.” Due to the present placement of the comma in the description for the two ammonium nitrate entries, the 0.2% combustible materials/substances are measured differently. This amendment ensures that the 0.2% combustible level is calculated as carbon in the case of organic substances.

Two new proper shipping names “Asbestos, amphibole (amosite, tremolite, actinolite, anthophyllite, crocidolite)” and “Asbestos, chrysotile” are proposed to be assigned to identification numbers UN2212 and UN2590, respectively. These new proper shipping names more appropriately describe the material than the present “UN2212, Blue asbestos (Crocidolite) or Brown asbestos (amosite, mysorite)” and “UN2590, White asbestos (chrysotile, actinolite, anthophyllite, tremolite).” In the scientific community, Asbestos is divided into two chemical group names, “Amphiboles” and “Chrysotile”. The amphibole group includes five different minerals (amosite, tremolite, actinolite, anthophyllite, crocidolite). The chrysotile group includes only the mineral chrysotile.

The proper shipping name for “UN3499, Capacitor, electric double layer (with an energy storage capacity greater than 0.3 Wh)” is amended by placing the phrase “electric double layer” in Roman type. This amendment is necessary to differentiate this HMT entry from the new HMT entry, Capacitor, asymmetric.

A new proper shipping name “Safety devices, electrically initiated” is proposed to be assigned to identification number UN3268. Current proper shipping names assigned to UN3268 are “Air bag inflators, or Air bag modules, or Seat-belt pretensioners.” The proposed proper shipping name more appropriately describes materials authorized under this HMT entry in conjunction with the proposed revision to special provision 160 to include a number of automotive industry life-saving appliances that are actuated by the electric signal of the crash sensor.

A new proper shipping name “Safety devices, pyrotechnic” is proposed to be assigned to identification number UN0503. The current proper shipping names assigned to UN0503 are “Air bag inflators, or Air bag modules, or Seat-belt pretensioners.” The proposed proper shipping name more appropriately describes Class 1 materials authorized under this HMT entry.

The proper shipping name for “UN1082, Trifluorochloroethylene, stabilized” is amended by adding “Refrigerant gas R 1113” as an alternative proper shipping name for consistency with the Dangerous Goods Lists of the various international standards and the HMT of the HMR. The proposed proper shipping name for UN1082 is

“Trifluorochloroethylene, stabilized or Refrigerant gas R 1113”

Amendments to Column (5) Packing Group

Section 172.101(f) describes Column (5) of the HMT and the designation of the packing group(s) assigned to each proper shipping name.

For the entries “UN3316, Chemical kits” and “UN3316, First aid kits” the Packing Groups II and III designations are proposed. The assignment of packing groups to these entries are not a new requirement; however, including packing group assignments in the HMT will ensure that shippers are aware that the most stringent packing group must be assigned to any individual substance in the kit in accordance 173.161(a)(2).

The HMT entries for several articles are revised to remove packing group assignments. For articles, the packing group does not relate to the degree of hazard posed by the material but rather is assigned generically to the article. There is limited value in requiring an indication of the packing group in association with the shipment. Currently and without specific rationale, some articles are assigned packing groups while others are not. This proposed change provides a level of consistency for all articles specifically listed in the HMT. In this NPRM, PHMSA is proposing to remove packing group assignments from the following HMT entries:

Amendments to the Column (7) Special Provisions

Section 172.101(h) describes Column (7) of the HMT and § 172.102(c) the special provisions assigned to specific entries in the HMT. The particular modifications to the entries in the HMT are discussed below. See Section 172.102 special provisions for a detailed discussion of the proposed additions, revisions, and deletions to the special provisions addressed in this NPRM.

In this NPRM, special provision 134 is added to the HMT entry “UN3072, Life-saving appliances, not self-inflating containing dangerous goods as equipment.” The addition of this special provision will clarify that equipment containing only lithium batteries must be consigned under the entries “Lithium batteries contained in equipment” or “Lithium batteries packed with equipment,” as appropriate.

Several HMT entries are revised to include new special provision 367. Special provision 367 authorizes the use of the “Paint related material” entries for consignments of packages containing “Paint” and “Paint related material” in the same package. This special provision also authorizes the proper shipping name “Printing ink related material” for consignments of packages containing “Printing Ink” and “Printing ink related material” in the same package.

In this NPRM, new special provision 367 is proposed to be assigned to the following entries:

In this NPRM, we propose to add new special provision 368 to the HMT entry “UN2910, Radioactive material, excepted package-limited quantity of material.”

In this NPRM, new special provision 369 is proposed to be assigned to the new HMT entry “UN3507, Uranium hexafluoride, radioactive material, excepted package, less than 0.1 kg per package, non-fissile or fissile-excepted.”

In this NPRM, new special provision 370 is proposed to be assigned to the HMT entry “UN0222, Ammonium nitrate.” This special provision contains qualifying language that previous to this NPRM, was part of the proper shipping name for UN0222.

In this NPRM, new special provision 371 is proposed to be assigned to the HMT entry “UN3164, Articles, pressurized pneumatic or hydraulic containing non-flammable gas.”

In this NPRM, new special provision 375 is proposed to be assigned to the HMT entries “UN3077, Environmentally hazardous substance, solid, n.o.s.” and “UN3077, Environmentally hazardous substance, liquid, n.o.s.”

In this NPRM, for the HMT Packing Group III entry “UN3089, Metal powders, flammable, n.o.s.” special provision IB6 is replaced with IB8 and special provisions IP2, and IP4 are added. IB8 is presently assigned to the Packing Group II entry, therefore, fiberboard, wooden and flexible IBCs are allowed for the Packing Group II materials, but are forbidden for the less dangerous Packing Group III substance. These proposed revisions will correct the inconsistency.

In this NPRM, new special provision A61 is proposed to be assigned to the HMT entries “UN 3107, Organic peroxide type E, liquid” and “UN 3109, Organic peroxide type F, liquid”.

Several HMT entries are revised to include new portable tank special provision TP47. Special provision TP47 indicates that the 2.5 year internal portable tank examination may be waived or substituted by other test methods or inspection procedures specified by the competent authority or its authorized body, provided that the portable tank is dedicated to the transport of the organometallic substances to which this tank special provision is assigned. However, this examination is required when the conditions of § 180.605(f) are met.

In this NPRM, new special provision TP47 is proposed to be assigned to the following entries:

Amendments to the Column (9) Quantity Limitations.

Section 172.101(j) describes Column (9) of the HMT and the quantity limitations for specific entries in the HMT. Furthermore, Columns (9A) and (9B) specify the maximum quantities that may be offered for transportation in one package by passenger-carrying aircraft or passenger-carrying rail car (Column (9A)) or by cargo-only aircraft (Column (9B)). The indication of “forbidden” means the material may not be offered for transportation or transported in the applicable mode of transport.

For the entry “UN3497, Krill meal” quantity limits of 15 kg and 50 kg for PG II, and 25 kg and 100 kg for PG III, are proposed for columns (9A) and (9B) respectively. Previously, there was no limit to the amount authorized to be shipped in one package. These new quantity limits are consistent with authorized quantity limits found in the ICAO TI.

At the 24th meeting the ICAO DGP, it was agreed to incorporate certain UN numbers contained in the UN Model Regulations, but not currently listed in the ICAO TI. For the entry “UN2216, Fish meal, stabilized or Fish scrap, stabilized,” the panel determined that it should be forbidden for transport on both cargo and passenger aircraft. Under the HMR, this entry is assigned a “W” in Column (1) meaning that the material is only subject to the requirements when offered or intended for transport by vessel. Because of this discrepancy, in this NPRM, PHMSA is soliciting public comment on any potential action to align with the ICAO TI (including potentially adding “A” to column one and forbidding this entry aboard both cargo and passenger aircraft) and what potential benefit or burden a change to these quantity limits for UN2216 could potentially impose upon shippers and air operators.

Amendments to the Column (10) vessel stowage requirements.

Vessel stowage location (10B).

Section 172.101(k) explains the purpose of column (10) of the HMT and prescribes the vessel stowage and segregation requirements for specific entries in the HMT. Column (10) is divided into two columns: Column (10A) [Vessel stowage] specifies the authorized stowage locations on board cargo and passenger vessels and column (10B) [Other provisions] specifies special stowage and segregation provisions.

The IMO, in amendment 37-14 of the IMDG Code, split their stowage and segregation column (16) in the dangerous goods list into two columns and assigned codes to the existing stowage, handling, and segregation text. The new first column (16a) in the IMDG Code is titled stowage and handling, and the second column (16b) is titled segregation. PHMSA is proposing to maintain the HMT’s current column 10A and 10B, while also harmonizing our vessel stowage codes in columns 10A and 10B as closely as possible with those in amendment 37-14 of the IMDG Code. There are several instances where PHMSA is proposing to maintain additional codes (see UN numbers 0019, 0020, 0021, 0301, 0303, 1017, 1131, 1389, 1392, 1420, 1422, 1780, 1942, 1950, 2679, 2912, 3015, 3071, 3101-3106, 3108-3110, 3242, 3323, and 3497) that vary from IMDG Code stowage and segregation requirements. These additional stowage and segregation provisions vary by UN number, but are considered additional precautions deemed necessary to ensure the safe transport of these commodities during transportation by vessel. PHMSA welcomes comments on the continued need and or the impact of maintaining this limited number of domestic variations from the international stowage, handling, and segregation requirements.

During the preparation of this NPRM, PHMSA and the United States Coast Guard conducted an extensive review of all HMT entries to verify that domestic entries correspond as closely as possible with the provisions found in the IMDG Code. PHMSA is proposing numerous changes to the codes found in the HMT’s column 10B [Other provisions] as a result of this review. The majority of the changes are a result of work done at the IMO to eliminate duplicate and unnecessary provisions. Some of the proposed changes to column 10B are proposed to harmonize existing differences in stowage, handling, and segregation provisions between the HMR and the IMDG Code. Recognizing that there are both shippers and carriers that only offer hazardous materials by vessel domestically, PHMSA seeks comments on the costs and benefits to these domestic shippers and carriers of harmonizing the stowage provisions of the HMR with the provisions of the IMDG Code as proposed in this NPRM. PHMSA also solicits comments on the costs and benefits were we to maintain domestic stowage differences within the HMR. A table of proposed changes, listed in alphabetical order, showing the proper shipping name, UN identification number, any stowage codes proposed for removal, and any stowage codes proposed for addition is provided below. If a column is blank, no changes are proposed. The meaning of the codes in column 10B can be found either in § 176.84 or are listed in the § 176.84 Section-by-Section change portion of this NPRM.

Appendix B to § 172.101

Appendix B to § 172.101 lists Marine Pollutants regulated under the HMR. In this NPRM, PHMSA is proposing to revise the List of Marine Pollutants by adding sixty-two new entries consistent with the IMDG Code. These changes are proposed to include those substances that, by virtue of meeting the Group of Experts on the Scientific Aspects of Marine Environmental Protection (GESAMP) defining criteria for marine pollutants, were either assigned a “P” in the dangerous goods list or identified in the alphabetical index to amendment 37-14 of the IMDG Code. The entry “Chlorotoluenes (meta-;para-)” would be removed based on its removal from the IMDG Code.

Section 172.102 Special Provisions

Section 172.102 lists special provisions applicable to the transportation of specific hazardous materials. Special provisions contain packaging requirements, prohibitions, and exceptions applicable to particular quantities or forms of hazardous materials. PHMSA is proposing the following revisions to § 172.102, special provisions:

Special Provision 28

Special provision 28 states that the dihydrated sodium salt of dichloroisocyanuric acid is not subject to the HMR. In this NPRM, PHMSA proposes to revise special provision 28 to convey that the dihydrated sodium salt of dichloroisocyanuric acid does not meet the definition of a Division 5.1 (oxidizer) and is not subject to the requirements of the subchapter unless it meets the criteria for inclusion in another Class or Division, such as Class 9, environmentally hazardous substance. Some formulations of the dihydrated sodium salt of dichloroisocyanuric acid meet the criteria for classification as an environmentally hazardous substance.

Special Provision 52

Special provision 52 authorizes use of the HMT entry “UN2067, Ammonium nitrate based fertilizer” for substances that do not exhibit explosive properties of Class 1 when tested in accordance with Test Series 1 and 2 of the UN Manual of Tests and Criteria, Part I. In this NPRM, PHMSA proposes to revise special provision 52 by removing the requirement to test in accordance with Test Series 1 because Test Series 2 determines whether such properties are indeed those of Class 1, not Test Series 1.

Special Provision 147

This special provision describes the composition of the material for which the use of the HMT entry “UN3375, Ammonium nitrate emulsion or Ammonium nitrate suspension or Ammonium nitrate gel, intermediate for blasting explosives” is authorized and prohibits the material from being classified and transported unless approved by the Associate Administrator. Special provision 147 requires that these substances must satisfactorily pass Test Series 8 of the UN Manual of Tests and Criteria, Part I, Section 18. Test Series 8 contains four test types. Tests 8(a), (b) and (c) are used for classification purposes while Test 8(d) is used to assess suitability for transport in portable tanks. The use of this entry (UN 3375) therefore requires only that Tests 8(a), (b) and (c) are satisfactorily passed. In this NPRM, PHMSA is proposing to revise special provision 147 by clarifying that Tests 8(a), (b) and (c), not the entire Test Series 8, are required for use in classification and subsequent approval by the Associate Administrator.

Special Provision 160

Special provision 160 is presently assigned to “UN3268, Air bag inflators, or Air bag modules, or Seat-belt pretensioners” in Class 9. Special provision 160 includes the requirement that air bag inflators and modules must be tested in accordance with Test series 6 (c) of Part I of the UN Manual of Tests and Criteria. In this NPRM, PHMSA is proposing to revise special provision 160 in conjunction with revising the proper shipping name for UN3268 to “Safety devices, electrically initiated.” The entry is revised to clarify that it applies to safety devices used in vehicles including vessels and aircraft, and pyromechanical devices that are added to the list of authorized devices. The development of safety products has seen significant progress since the introduction of UN3268 and the range of current products extends beyond what can presently be assigned to UN3268. Some of the newer safety products include elements that are actuated by the electrical signal of the crash sensor (e.g. pyromechanical devices). Examples include: Devices that interrupt the electrical connection in case of emergency by disconnecting the main power cable in the vehicle from the battery to prevent short circuit and consequentially minimize the risk of fire in the vehicle; and actuators which are used for active headrests or for pedestrian protection to release special hinges of the engine hood. In addition, PHMSA is proposing to clarify that this entry does not apply to life saving appliances described in § 173.219 (UN Nos. 2990 and 3072).

Special Provision 161

Special provision 161 required that for domestic transportation the alternate shipping description “Articles, pyrotechnic for technical purposes” be used to describe air bag inflators, air bag modules and seat-belt pretensioners (UN0503) meeting the criteria for a Division 1.4G explosive. This was done to ensure a different shipping name was used to describe these articles to differentiate them from air bag inflators, air bag modules and seat-belt pretensioners (UN3268) in Class 9. In this NPRM, PHMSA proposes, consistent with the UN Model Regulations, to adopt new proper shipping names for these items, “Safety devices” (UN3268) for these articles assigned to Class 9, and “Safety Devices, pyrotechnic” (UN0503) for these articles assigned to Division 1.4G. Since the proper shipping names for these items would no longer the same, there would be no need to use a different proper shipping name for these articles assigned to Division 1.4G. Therefore the need for this special provision would be obsolete and we propose to delete it from the regulations and to delete its reference from the UN0503 entry in the HMT. Under this proposed revision, for domestic transportation, air bag inflators, air bag modules and seat-belt pretensioners (UN0503) meeting the criteria for a Division 1.4G explosive, that are currently described as “Articles, pyrotechnic for technical purposes” would be described as “Safety devices, pyrotechnic” (UN0503).

Special Provision 238

Special provision 238 addresses the shipment of neutron radiation detectors. In this NPRM, PHMSA proposes to revise special provision 238 to align with the UN Model Regulations special provision 373 by expanding the transport conditions for neutron radiation detectors and radiation detection systems containing such detectors. Paragraph a. is restructured into: (a)(1), General transport requirements; (a)(2), requirements for radiation detectors transported as individual components; and (a)(3), requirements for completed neutron radiation detection systems containing detectors. Consistent with the UN Model Regulations, PHMSA is proposing the following revisions to the transport conditions: [1] In (a)(1), increase the total amount of gas authorized per detector from 12.8 grams to 13 grams; clarify that the minimum burst pressure is demonstrated by design type qualification testing; and add a new leaktightness standard; [2] in (a)(2), clarify that in addition to being packed in a strong outer package, that the completed package must be capable of withstanding a drop of 1.8 meters (6-foot) without leakage of gas contents; and increase the total amount of gas from all detectors per outer packaging from 51.2 grams to 52 grams; and [3], in (a)(3), add a new requirement that for completed neutron radiation detection systems, the detectors must be contained in a strong sealed outer casing; and add a new requirement that the completed system must be capable of withstanding a 1.8 meter (6-foot) drop test without leakage unless a system’s outer casing affords equivalent protection.

Special Provision 342

This special provision, assigned to “UN1040, Ethylene oxide or Ethylene oxide with nitrogen” allows sterilization devices containing ethylene oxide, conforming to the conditions in the special provision, and packaged in accordance with § 173.4a of the HMR to be offered for transportation and transported by all modes even though Column (9A) of the § 172.101 HMT lists the material as forbidden by passenger aircraft.

Consistent with the ICAO TI, in this NPRM, PHMSA is proposing to further clarify that irrespective of both Columns (9A) and (9B) of the § 172.101 HMT listing the material as forbidden, ethylene oxide conforming to the conditions in the special provision is eligible for air transport. Specifically, we are proposing to supplement the language in this special provision “irrespective of the restriction of § 173.4a(b)” with “and the indication of “forbidden” in columns (9A) and (9B) of the § 172.101 table.”

Special Provision 362

Special provision 362 specifies when a material can be considered a chemical under pressure. Specifically, the special provision states that classification of these materials is to be based on hazard characteristics of the components in the propellant, the liquid, or the solid forms. In this NPRM, PHMSA proposes to revise special provision 362 by adding a new paragraph (f) to clarify that chemicals under pressure containing components forbidden for transport on both passenger and cargo aircraft must not be transported by air.

Special Provision 367

A new special provision 367 is proposed to clarify that the proper shipping name “Paint related material” or “Printing ink related material” may be used for consignments of packages containing both “Paint” and “Paint related material” or “Printing Ink” and “Printing ink related material” in the same package and sharing the same identification number (UN 1210, UN 1263, UN 3066, UN 3469, or UN 3470). For example, “UN1263, Paint including paint, lacquer, enamel, stain, shellac solutions, varnish, polish, liquid filler, and liquid lacquer base” and “UN1263, Paint related material” contained in the same package, may be consigned under the entry “UN1263, Paint related material including paint thinning, drying, removing, or reducing compound.” Paint mainly consists of resin, pigment and solvent. Thinning compound consists of solvent as well. Thus under the same UN entry, there is no difference between “Paint” and “Paint related material” with regard to transport requirements.

Special Provision 368

In this NPRM, PHMSA proposes adding new special provision 368 and assigning it to “UN2910, Radioactive material, excepted package-limited quantity of material” to clarify that in the case of non-fissile or fissile-excepted uranium hexafluoride, the material must be classified under UN3507 or UN2978.”

Special Provision 369

The 18th Revised Edition of the UN Model Regulations has adopted a new proper shipping name of “UN3507, Uranium hexafluoride, radioactive material, excepted package, less than 0.1 kg per package, non-fissile or fissile-excepted”, to address small quantities of uranium hexafluoride containing corrosive properties, thus a new special provision is necessary in the HMR. In this NPRM, PHMSA proposes the assignment of special provision 369 to UN3507 to specify a primary hazard of Class 8 with subsidiary risk of Class 7, subject to certain conditions. The provisions in special provision 369 relating to conditions required when it is evident that packages have leaked are consistent with language proposed for inclusion in § 173.443(e) in HM-250 [Docket No. PHMSA-2009-0063]. PHMSA notes that if the proposed addition of these provisions in § 173.443(e) occurs, the portion of the text proposed in this NPRM referring to leaking packages may be replaced with a reference to § 173.443(e).

Special Provision 370

In this NPRM, PHMSA proposes adding new special provision 370 and assigning it to the revised HMT entry “UN0222, Ammonium Nitrate.” As a result of the comma placement in the descriptions for the two ammonium nitrate entries, UN1942 and UN0222, the manner in which the 0.2% combustible materials/substances level is calculated would lead to different analyses and different, non-comparable results. In conjunction with revising the proper shipping name for UN0222 by removing the qualifying text, in this NPRM, PHMSA is proposing a new special provision assigned to UN0222 to include the qualifying text previously attached to the proper shipping name and further clarify the criteria for use of this entry by stipulating the following conditions: (1) Ammonium nitrate with more than 0.2% combustible substances, including any organic substance calculated as carbon, to the exclusion of any added substance; or (2) ammonium nitrate with not more than 0.2% combustible substances, including any organic substance calculated as carbon, to the exclusion of any added substance, that gives a positive result when tested in accordance with Test Series 2 of the UN Manual of Tests and Criteria, Part I.

Special Provision 371

In this NPRM PHMSA proposes adding a new special provision 371 and assigning it to “UN3164, Articles, pressurized pneumatic or hydraulic containing non-flammable gas.” This special provision sets forth the requirements for confetti-shooters pressurized with gas instead of pyrotechnics. The shooter consists in principle, of a jacket of cardboard, the pressurized receptacle filled with compressed air or nitrogen, a lock mechanism made of plastics, a plug of rubber and a metal cap for closing the receptacle and different types of confetti. By turning a ring, or the bottom part of the shooter, a mechanism is unlocked and the pressurized gas is discharged so that the confetti is shot away for a few meters. This type of shooter does not contain any amount of explosives and therefore cannot be assigned to Class 1, and does not meet the requirements for gas cartridges or small pressure receptacles. The requirements set forth in the special provision ensure the same level of safety as for confetti-shooters with pyrotechnics.

Special Provision 372

In this NPRM, PHMSA proposes adding new special provision 372 and assigning it to the new HMT entry “UN3508, Capacitor, asymmetric.” This special provision states that this entry applies to asymmetric capacitors with an energy storage capacity greater than 0.3 watt hours (Wh) and that asymmetric capacitors with an energy storage capacity of 0.3 Wh or less are not subject to the requirements of this subchapter. This special provision also provides that nickel-carbon asymmetric capacitors containing Class 8 alkaline electrolytes must be transported as UN 2795, Batteries, wet, filled with alkali, electric storage.

Special Provision A60

Special provision A60 permits “UN2014, Hydrogen peroxide, aqueous solution,” to be transported in excepted quantities. The special provision authorizes packagings to include a vent to permit the slow escape of gas (i.e. not more than 0.1 mL/hour per 30 mL inner packaging at 20 °C (68 °F) produced from gradual decomposition. As venting is permitted, the requirements of §§ 173.24(g)(1) and 173.27(c) are impracticable and should not apply. To address the issue, the ICAO DGP adopted a proposal to clarify these general requirements prohibiting venting should not be applicable. In this NPRM, we are proposing to harmonize with the ICAO TI with regard to waiving the general requirements of §§ 173.24(g)(1) and 173.27(c). Special provision A60 is revised accordingly.

Special Provision A61

In this NPRM, PHMSA proposes adding new special provision A61 and assigning it to the to the HMT entries “UN 3107, Organic peroxide type E, liquid” and “UN 3109, Organic peroxide type F, liquid.” PHMSA proposes to align with Packing Instruction 570 of the ICAO TI to allow for limited venting of oxygen in the case of specialized peroxyacetic acid packagings when transported by cargo aircraft provided the packaging requirements of this special provision are met. It was reported to the ICAO DGP that peroxyacetic acid was commonly used as a sterilizer for health care purposes and that there is a need to transport the material by air for use in sterilizing medical equipment using custom packagings. The basis for the requirements that these specialized packagings must meet originated from exemptions to permit the transport of this substance in small containers approved by appropriate national authorities in four States. The inclusion of this new special provision will eliminate the need for these exemptions and facilitate international transport.

IBC Codes and IP Codes

The introductory paragraph (c)(4) states that packagings are authorized for the Packing Group III entries of specific proper shipping names when either Special Provision IB3 or IB8 is assigned to that entry in the § 172.101 Table. When no IB code is assigned in the § 172.101 Table for a specific proper shipping name, or in § 173.225(e) Organic Peroxide Table for Type F organic peroxides, use of an IBC or Large Packaging for the material may be authorized when approved by the Associate Administrator.

In this NPRM, PHMSA proposes to revise the introductory paragraph (c)(4) by adding a reference to § 173.185, preceding the reference to § 173.225(e), thereby authorizing the use of Large Packagings for lithium batteries without assigning IB3 or IB8 to the corresponding entries in the § 172.101 Table. See Section 173.185 Lithium batteries for a detailed discussion of the proposed a use of rigid large packagings for lithium batteries.

In two final rules published in the Federal Register on January 19, 2011 (76 FR 3308; HM-215K) and January 7, 2013 (78 FR 988; HM-215L) the Table 1 (IBC Codes) in paragraph (c)(4) were editorially revised to remove UN Specifications 31A, 31B, 31N, 31H1, 31H2, 31HZ1, and 31HZ2 from IBC Codes IB4 through IB8. The revisions were consistent with amendments to international standards that removed the specifications from the indicated codes in the table because IBC Codes IB4 through IB8 are assigned to solids, whereas, UN Specifications 31A, 31B, 31N, 31H1, 31H2, 31HZ1, and 31HZ2 are authorized for transportation of liquids in IBC Codes IB1 through IB3 and are assigned to liquid materials only. Information presented to the UN Committee of Experts on the Transport of Dangerous Goods (UNCOE) in this last biennium indicated that the removal of the above UN Specifications from IBC Codes IB4 through IB8 has created a problem. Prior to implementation of these revisions, certain liquid IBC types were used to transport powdery solids and solids that become liquid under conditions of transport. These solids may be loaded and unloaded from the IBC in liquid form raising the question of whether the remaining IBC’s, which are intended for gravity or pressure discharge, are appropriate. The UN sub-committee adopted a proposal to reinstate the IBC’s that were previously authorized. In this NPRM, we are proposing to harmonize with the UN Model Regulations by revising the IBC Codes IB4 through IB8 in paragraph (c)(4), the Table 1 (IBC Codes) to reinstate IBC’s previously authorized.

A new IP Code 16 is added and assigned to UN3375. Consistent with international regulations, this special provision would authorize require IBCs of type 31A and 31N if approved by the Associate Administrator.

Special Provision TP47

In this NPRM, PHMSA proposes adding new special provision TP47 and assigning it to the organometallic substance HMT entries UN3393 through UN3399. The special provision waives the 2.5 year internal inspection for portable tanks used for the transport of liquid and solid organometallic substances provided that the portable tank remains in the dedicated service of transporting organometallic substances. However, all other required 2.5 year inspections and tests would still be performed, as well as the full 5 year periodic test and inspection, which would include an internal inspection.

This special provision is added for the following reasons. Before an internal inspection can be performed, the tank must be cleaned and purged. In this process, it is difficult to ensure that all water or other impurities or contaminants introduced during the cleaning are fully removed before organometallic substances are again introduced into the tank potentially resulting in a dangerous reaction or have an effect on the purity of the product. Since these organometallic substances are fully compatible with, and, in particular, are not corrosive to the materials of construction used in such tanks, the likelihood that an internal inspection will reveal any corrosion, pitting or other deterioration of the tank is unlikely. In order to increase safety and avoid the risk of a dangerous reaction or product contamination the 2.5 year internal inspection is waived, provided the portable tank remains in the dedicated service of transporting organometallic substances and the tank does exhibit damaged or corroded areas, or leakage, or other conditions that indicate a deficiency in accordance with § 180.605(f).

Section 172.315

To promote the uniformity of markings, the UN Model Regulations have adopted revisions to clarify and standardize the specifications for limited quantity marking, including the air limited quantity marking. In this NPRM, PHMSA is proposing to revise the specifications for the limited quantity markings prescribed in § 172.315(a)(2) and (b)(2) to be consistent with the revised specifications for these markings in the UN Model Regulations. Also consistent with the UN Model Regulations, we propose to allow manufacturers and printers necessary time to retool to produce markings that conform to the revised specifications, and to allow for the depletion of supplies of existing markings. PHMSA proposes a transitional period to authorize a limited quantity marking that is in conformance with the requirements of the regulations in effect on October 1, 2012, to be used until December 31, 2016.

Section 172.317

To promote the uniformity of the “Keep Away From Heat” handling mark throughout the international transportation community, revisions have been adopted in the ICAO Technical Instructions to clarify and standardize the specifications for this hazard communications element. In this NPRM, PHMSA is proposing to revise the specifications for the “Keep Away From Heat” handling mark prescribed in § 172.317(b) to be consistent with the revised specifications for this marking in the ICAO TI. Also, we propose to allow manufacturers and printers necessary time to retool to produce markings that conform to the revised specifications, and to allow for the depletion of supplies of existing markings. Thus we propose a transitional period to authorize a “Keep Away From Heat” handling mark that is in conformance with the requirements of the regulations in effect on October 1, 2012, to be used until December 31, 2016.

Section 172.322

In this NPRM, PHMSA is proposing to clarify in § 172.322(a)(2) and (b), that the marking requirements for marine pollutants are required unless otherwise provided for in the regulations.

In § 172.322 paragraph (e) PHMSA is proposing to delete the obsolete date of January 14, 2010 for the requirements for the marine pollutant mark.

To promote the uniformity of the marine pollutant mark throughout the international transportation community, the UN Model Regulations have adopted revisions to clarify and standardize the specifications for this hazard communications element. In this NPRM, PHMSA is proposing to revise the specifications for the marine pollutant mark prescribed in § 172.322(e) to be consistent with the revised specifications for this marking in the UN Model Regulations. Also, to allow manufacturers and printers necessary time to retool to produce markings that conform to the revised specifications, and to allow for the depletion of supplies of existing markings, we propose a transitional period to authorize a marine pollutant mark that is in conformance with the requirements of the regulations in effect on October 1, 2012, to be used until December 31, 2016.

Section 172.327

To promote the uniformity of markings, in this NPRM, PHMSA is proposing to revise and clarify the specifications for the “petroleum sour crude oil” mark prescribed in § 172.327(a) to be consistent with the revised specifications for markings in the UN Model Regulations. Also, to allow manufacturers and printers necessary time to retool to produce markings that conform to the revised specifications, and to allow for the depletion of supplies of existing markings, we propose a transitional period to authorize a “petroleum sour crude oil” mark that is in conformance with the requirements of the regulations in effect on October 1, 2012, to be used until December 31, 2016.

Section 172.407

To promote the uniformity of hazard communications labels throughout the international transportation community, revisions have been adopted in the UN Model Regulations to clarify and standardize the specifications for labels. In this NPRM, PHMSA is proposing to revise the specifications for labels prescribed in § 172.407(a) to be consistent with the revised specifications for labels in the UN Model Regulations. In addition, PHMSA is proposing to revise the (d)(2)(iii) that provides a color alternative for the symbol on the ORGANIC PEROXIDE LABEL to be consistent with the UN Model Regulations. Also to be consistent with the UN Model Regulations, and to allow manufacturers and printers necessary time to retool to produce labels that conform to the revised specifications, and to allow for the depletion of supplies of existing labels, we propose a transitional period to authorize a label that is in conformance with the requirements of the regulations in effect on October 1, 2012, to be used until December 31, 2016.

Finally, PHMSA is proposing to add paragraph (d)(2)(iv) to permit, consistent with the UN Model Regulations, a FLAMMABLE GAS label to be displayed on cylinders and gas cartridges for liquefied petroleum gases, where the symbol may be shown in the background color of the receptacle if adequate contrast is provided.

Section 172.512

The placarding requirements for freight containers and aircraft unit load devices are described in § 172.512. The reference in § 172.512(a)(3) to part 7; chapter 2, section 2.7 of the ICAO TI in this paragraph is inaccurate. This reference became inaccurate in the 2013-2014 Edition of the ICAO TI where the ICAO DGP re-designated part 7; chapter 2; section 2.6 as a new requirement for visibility of labels, moving all subsequent sections up. Part 7; chapter 2, section 2.7 of the ICAO TI now refers to replacement of labels, whereas section 2.8 refers to identification of unit load devices containing dangerous goods. PHMSA is revising this paragraph for the correct reference to cite part 7; chapter 2, section 2.8.

Section 172.519

To promote the uniformity of hazard communications placards throughout the international transportation community, revisions have been adopted in the UN Model Regulations have adopted revisions to clarify and standardize the specifications for placards. In this NPRM, PHMSA is proposing to revise the specifications for placards prescribed in § 172.519(c) to be consistent with the revised specifications for labels in the UN Model Regulations. Additionally, to allow manufacturers and printers necessary time to retool to produce placards that conform to the revised specifications, and to allow for the depletion of supplies of existing placards, a transitional period is proposed. This transitional period would authorize a placard that is in conformance with the requirements of the regulations in effect on October 1, 2012, to be used until December 31, 2016. Finally, PHMSA realizes that in domestic transportation, numerous placards of a semi-permanent nature are in service. PHMSA is proposing that for domestic transportation, a placard manufactured prior to January 1, 2017, in conformance with the requirements of the regulations in effect on October 1, 2012, may continue in service until the end of its useful life provided the color tolerances are maintained and are in accordance with the display requirements of the subchapter.

Part 173

Section 173.2a

Section 173.2a outlines classification requirements for materials having more than one hazard. In this NPRM, PHMSA is proposing to amend paragraph (a)(1) to note that shipments of uranium hexafluoride, radioactive material, excepted package, less than 0.1 kg per package are not required to apply the radioactive hazard as the primary hazard. This change is being proposed to incorporate the transportation provisions for excepted packages of uranium hexafluoride adopted in the 18th Revised Edition of the UN Model Regulations, the IMDG Code and the ICAO TI.

Section 173.3

To promote the uniformity of hazard communications markings throughout the international transportation community, the UN Model Regulations have adopted revisions to clarify and standardize the specifications for placards. In this NPRM, PHMSA is proposing to revise the specifications for markings for salvage packagings prescribed in § 173.3(c)(3); salvage cylinders prescribed in § 173.3(d)(3); and to prescribe requirements for the marking of the proposed large salvage packaging in § 173.3(f) to be consistent with the revised specifications for salvage packaging markings in the UN Model Regulations. Also, to be consistent with the UN Model Regulations, and to allow shippers necessary time to implement the new marking requirements, we propose a transitional period to authorize a marking that is in conformance with the requirements of the regulations in effect on October 1, 2012, to be used until December 31, 2016. Finally, PHMSA realizes that in domestic transportation numerous salvage and salvage cylinder markings are in service that are of a more permanent nature. In recognition of this PHMSA is proposing that for domestic transportation, a salvage packaging or a salvage cylinder that is permanently marked prior to January 1, 2017 in conformance with the requirements of the regulations in effect on October 1, 2012, may continue in service until the end of its useful life.

Also PHMSA is proposing to add a new paragraph (f) to § 173.3 authorizing and prescribing the use of large salvage packaging for all modes of transportation other than air.

Section 173.4a

To promote the uniformity of markings, throughout the international transportation community, the UN Model Regulations have been revised to clarify and standardize the specifications for the excepted quantities marking. In this NPRM, PHMSA is proposing to revise the specifications for the excepted quantities marking prescribed in § 173.4a(g)(2) to be consistent with the revised specifications for these markings in the UN Model Regulations. Also consistent with the UN Model Regulations, we propose to allow manufacturers and printers necessary time to retool to produce markings that conform to the revised specifications, and to allow for the depletion of supplies of existing markings, a transitional period is being proposed to authorize an excepted quantities marking that is in conformance with the requirements of the regulations in effect on October 1, 2012, to be used until December 31, 2016.

Section 173.9

To promote the uniformity of markings, UN Model Regulations have been revised to clarify and standardize the specifications for the fumigant marking. In this NPRM, PHMSA is proposing to revise the specifications for the fumigant marking prescribed in § 173.9(e) to be consistent with the revised specifications for these markings in the UN Model Regulations. Also consistent with the UN Model Regulations, to allow manufacturers and printers necessary time to retool to produce markings that conform to the revised specifications, and to allow for the depletion of supplies of existing markings, we propose a transitional period to authorize a fumigant marking that is in conformance with the requirements of the regulations in effect on October 1, 2012, to be used until December 31, 2016.

Section 173.11

In this NPRM, PHMSA proposes to add a new § 173.11 providing exceptions to the regulations for certain lamps containing hazardous materials based on their transport conditions, the quantity of hazardous materials contained in each lamp or package, and the type of packaging. This proposed new section is consistent with newly adopted provisions in the UN Model Regulations.

Section 173.24

In this NPRM, PHMSA proposes to revise § 173.24 to authorize the use of supplementary packagings within an outer packaging (e.g., an intermediate packaging or a receptacle inside a required inner packaging) in addition to what is required by the regulations provided all applicable requirements are met and, if appropriate suitable cushioning is used to prevent movement within the packaging. This proposed revision is consistent with newly adopted provisions in the UN Model Regulations.

Section 173.25

To promote the uniformity of markings, the UN Model Regulations have been revised to clarify and standardize the specifications for the overpack marking. In this NPRM, PHMSA is proposing to revise the specifications for the overpack marking prescribed in § 173.25(a)(4) to be consistent with the revised specifications for these markings in the UN Model Regulations. Also consistent with the UN Model Regulations, to allow manufacturers and printers necessary time to retool to produce markings that conform to the revised specifications, and to allow for the depletion of supplies of existing markings, we propose a transitional period to authorize an overpack marking that is in conformance with the requirements of the regulations in effect on October 1, 2012, to be used until December 31, 2016.

Section 173.62

Consistent with the UN Model Regulations, in this NPRM, PHMSA is proposing to revise § 173.62 relating to specific packaging requirements for explosives as follows:

In paragraph (b), in the Explosives Table, the entry for UN0222 is revised to expand the packaging authorizations to include Packing Instruction 117 in addition to the existing Packaging Instructions 112(b) and 112(c).

In paragraph (c), in the Table of Packing Methods, Packing Instruction 116 would be revised to delete provision 5, which states that woven plastic bags (5H2 or 5H3) must be used only for UN 0082, 0241, 0331 and 0332. Packing Instruction 117 would be revised to add provision 5 which states, “For UN0222, when other than metal or rigid plastics IBCs are used, they must be offered for transportation in a closed freight container or a closed transport vehicle.”; and provision 6 which states, “For UN0222, flexible IBCs must be sift-proof and water-resistant or must be fitted with a sift-proof and water-resistant liner.” Packing Instructions 131 and 137 would be revised to expand the authorization for outer packagings to include solid plastic boxes (4H2).

Section 173.115

Section 173.115 prescribes the definitions for Class 2 materials. In this NPRM a new paragraph (m) is proposed to define the term “Adsorbed gas”. The term means a gas which when packaged for transport is adsorbed onto a solid porous material resulting in an internal receptacle pressure of less than 101.3 kPa at 20 °C and less than 300 kPa at 50 °C.

Currently the HMR do not prescribe requirements for the transport of adsorbed gases. In this NPRM, PHMSA is proposing to adopt various transportation requirements for adsorbed gases. Prior to adoption of such standards, the term “Adsorbed gas” must be defined. Therefore in this NPRM we are proposing to adopt the above definition of an adsorbed gas based on the definition found in the 18th Revised Edition of the UN Model Regulations, the IMDG Code and the ICAO TI.

Section 173.121

Section 173.121 prescribes the requirements for the selection of packing groups for Class 3 flammable liquids. Paragraph (b) of this section describes the criteria for inclusion of viscous Class 3 materials in Packing Group III. Paragraph (b)(1)(ii) currently states that the mixture cannot contain any substances with a primary or subsidiary risk of Division 6.1 or Class 8. In this NPRM, PHMSA proposes to revise paragraph (b)(1)(ii) to clarify that a mixture or any separated solvent cannot contain any substances with a primary or subsidiary risk of Division 6.1 or Class 8. This proposed change is consistent with the current language in the 18th Revised Edition of the UN Model Regulations, the IMDG Code and the ICAO TI.

Section 173.127

In this NPRM, PHMSA is proposing to revise § 173.127(a) to authorize an alternative test for assigning packing groups to Division 5.1 oxidizing solids. The proposed test is in addition to the currently authorized test using potassium bromate. The alternative test uses calcium peroxide as a reference substance which is neither carcinogenic nor as acutely toxic as potassium bromate. In addition, the proposed alternative test replaces the highly subjective visual determination of the burning time with a gravimetric determination of the burning rate. This change is consistent with the test adopted into the UN Model Regulations.

Section 173.151

Section 173.151 provides exceptions for Class. In this NPRM PHMSA is proposing to revise paragraph (b) to replace a pre-existing paragraph (b)(2) relating to exceptions for charcoal briquettes (NA1361) that was inadvertently deleted in the final rule dated January 7, 2013 (HM-215K; 78 FR 1101).

Section 173.161

Section 173.161 prescribes packaging requirements for chemical kits and first aid kits that contain small amounts of hazardous materials. Paragraph (b)(2) contains the requirement that “The packing group assigned to the chemical kit and first aid kit as a whole must be the most stringent packing group assigned to any individual substance in the kit.” This requirement creates problems for shippers and air transport acceptance personnel because it does not specify what must be shown for the packing group on the shipping paper or what packaging standard must be applied to kits containing hazardous materials to which no packing group is assigned. In this NPRM, PHMSA is proposing to revise paragraph (b)(2) to require that for kits containing only hazardous materials to which no packing group is assigned, a packing group need not be indicated on the shipping paper although such packagings shall meet the Packing Group II performance level.

Section 173.164

Section 173.164 prescribes requirements for the transportation of Mercury (metallic and articles containing mercury). In this NPRM, PHMSA is eliminating the existing exception for lamps containing mercury in paragraph (b)(5). This paragraph will be redundant and unnecessary since this exception will be covered in the proposed new § 173.11 relating to exceptions for shipment of lamps containing hazardous materials.

Section 173.166

Section 173.166 prescribes requirements for the transportation of air bag inflators, air bag modules and seat-belt pretensioners, UN3268 and UN0503. Due to technological developments, new safety devices for vehicles are becoming available. The devices include pyromechanical devices that meet the definition of a hazardous material but are not accurately described by the proper shipping names Air bag inflators, Air bag modules, or Seat-belt pretensioners. The proper shipping name for these devices has been revised in the UN Model Regulations to “Safety devices, electrically initiated” for UN 3268 and “Safety devices, pyrotechnic” for UN0503. Consistent with the UN Model Regulations, in this NPRM, PHMSA is proposing to adopt these revised proper shipping names and revise § 173.166 to adopt the term “Safety Devices” for these items. An entry for the existing proper shipping name “Air bag inflators, or Air bag modules, or Seat-belt pretensioners” has been left in the § 172.101 Hazardous Materials Table to direct the reader to the new proper shipping names “Safety devices, electrically initiated” and “Safety devices, pyrotechnic.”

Also, the current § 173.166(b)(1)(iv) provides that under certain conditions a Class 9 (UN3268) air bag inflator, air bag module, or seat-belt pretensioner design is not required to be submitted to the Associate Administrator for approval or assigned an EX number. Air bag inflators, air bag modules, and seat-belt pretensioners have a long history of safety in their design and manufacture. However, new types of safety devices such as pyromechanical devices do not yet have an established history. Therefore in the interest of safety PHMSA is proposing not to extend this exception to all Class 9 safety devices but only maintain this exception for air bag inflators, air bag modules, and seat-belt pretensioners and still require that other types of safety devices, such as pyromechanical devices, that are candidates for Class 9 be submitted to the Associate Administrator for approval or assigned an EX number. Finally, in this NPRM, PHMSA proposes to add a new paragraph (d)(5) to § 173.166 to permit the continued transportation of an air bag inflator, air bag module, or seat-belt pretensioner that was classed and approved for transportation prior to January 1, 2015 under the terms of the existing approval, using the proper shipping name “Safety Devices” or “Safety Devices, Pyrotechnic” as appropriate.

Section 173.167

Section 173.167 prescribes the requirements for consumer commodities intended for air transportation. In this NPRM, PHMSA is proposing to revise the drop test requirements in (a)(4) by including the criteria for passing the test. A completed consumer commodity package will be considered to have passed the drop test if the outer packaging does not exhibit any damage liable to affect safety during transport and there is no leakage from the inner packaging(s).

Section 173.176

Section 173.176 addresses capacitors by prescribing the testing, marking, safety, and packaging requirements for electric double layer capacitors with energy storage capacity greater than 0.3 watt hours (Wh). In this NPRM, PHMSA is proposing to revise section 173.176 to include provisions for asymmetric capacitors in accordance with the new HMT entry “UN3508, Capacitor, asymmetric (with an energy storage capacity greater than 0.3Wh).” In addition, paragraph (a)(5) presently requires that capacitors must be marked with the energy storage capacity in Wh. As many pre-existing capacitors do not have Wh marking they are not permitted to be transported even when all other requirements of this section are met. In this NPRM, PHMSA is proposing to amend paragraph (a)(5) to require that the Wh marking is required for non-asymmetric capacitors manufactured after December 31, 2013 and for asymmetric capacitors manufactured after December 31, 2015.

Section 173.181

Section 173.181 prescribes the non-bulk packaging requirements applicable to pyrophoric liquids. On January 7, 2013, PHMSA published final rule PHMSA-2012-0027 (HM-215L) [78 FR 987] to maintain alignment with international standards by incorporating various amendments, including changes to proper shipping names, hazard classes, packing groups, special provisions, packaging authorizations, air transport quantity limitations, and vessel stowage requirements. In that final rule PHMSA revised paragraphs (b) and (c) to add authorizations for additional authorized packagings for these materials. Paragraphs (c) 1-3 were inadvertently deleted due to an incorrect amendatory instruction and in this NPRM PHMSA is proposing to place paragraphs (c) 1-3 back into § 173.181 as they were prior to the publication of HM-215L. It was never PHMSA’s intention to remove these important safety provisions for the transport of pyrophoric liquids, and we ask individuals who package and offer these materials to continue to abide by these requirements pending their reinsertion in the HMR.

Section 173.185

In this NPRM, PHMSA is proposing to add paragraph (b)(6) and revise paragraph(f)(3) to authorize and prescribe the use of a large packaging for a single large lithium battery or a battery contained in equipment. This authorization does not include transportation by aircraft. The proposed addition of this packaging type into this section is consistent with provisions for lithium batteries in the UN Model Regulations.

The ICAO DGP took a decision during the most recent biennium to remove the alternative written documentation option in Section IB of ICAO Packing Instructions 965 and 968 and instead require a standard transport document (shipping paper). Section IB is applicable to packages that exceed the number or quantity (mass) limits for smaller lithium batteries in Section II of Packing Instructions 965 and 968 excepting such packages from specification packaging requirements when containing no more than 2.5 kg of lithium metal cells or batteries or 10 kg of lithium ion cells or batteries per package. As this revision will appear in the 2015-2016 Edition of the ICAO TI, in this NPRM PHMSA is proposing to amend paragraph (c)(4)(v) to require a shipping paper for these packages containing no more than 2.5 kg of lithium metal cells or batteries or 10 kg of lithium ion cells or batteries per package. PHMSA is seeking input as to the costs and benefits of harmonizing the provisions of the HMR with the provisions of the ICAO Technical Instructions by requiring shipping papers as opposed to alternative documentation. PHMSA also solicits comments on the costs and benefits of maintaining a domestic difference within the HMR to continue to allow the use of the alternative documentation in lieu of a shipping paper as required by the ICAO Technical Instructions.

The ICAO Working Group on Lithium Batteries, at their April 2014 meeting, forbid the shipment of lithium metal cells and batteries as cargo on passenger aircraft with the exception of lithium metal cells and batteries packed with or contained in equipment not exceeding 5 kg net weight. This prohibition of lithium metal batteries as cargo on passenger aircraft is consistent with current HMR requirements. As a consequence to this prohibition, Section II of Packing Instruction 968 in the ICAO TI was amended to require shipments of small lithium metal cells and batteries to display the “CARGO AIRCRAFT ONLY” label where previously only a lithium battery handling marking was required. Presently under the HMR, a package containing such lithium metal cells or batteries as provided in § 173.185(c)(1)(iii), is required to be marked “PRIMARY LITHIUM BATTERIES—FORBIDDEN FOR TRANSPORT ABOARD PASSENGER AIRCRAFT” or “LITHIUM METAL BATTERIES—FORBIDDEN FOR TRANSPORT ABOARD PASSENGER AIRCRAFT.” Following the change to the ICAO TI, the present text marking will now be redundant for international shipments. In this NPRM, PHMSA is proposing to provide an alternative to the existing marking requirement in § 173.185(c)(1)(iii) with the option to display a “CARGO AIRCRAFT ONLY” label. This allowance to either utilize the current marking or the “CARGO AIRCRAFT ONLY” label will provide shippers with the flexibility to utilize supplies of preprinted markings or packagings, while also allowing shippers to transition to the use of the “CARGO AIRCRAFT ONLY” if desired.

Section 173.199

To promote the uniformity of markings, the UN Model Regulations have been revised to clarify and standardize the specifications for the square-on-point marking for Category B infectious substances. In this NPRM, PHMSA is proposing to revise the specifications for the Category B infectious substance marking prescribed in § 173.199(a)(5) to be consistent with the revised specifications for these markings in the UN Model Regulations. Also consistent with the UN Model Regulations, to allow manufacturers and printers necessary time to retool to produce markings that conform to the revised specifications, and to allow for the depletion of supplies of existing markings, we propose a transitional period to authorize a Category B infectious substance marking that is in conformance with the requirements of the regulations in effect on October 1, 2012, to be used until December 31, 2016.

Section 173.225

Section 173.225 prescribes packaging requirements and other provisions for organic peroxides. In this NPRM, PHMSA is proposing to revise the Organic Peroxide Portable Tank Table in paragraph (g). PHMSA proposes to revise the entry in the second column of the table pertaining to the hazardous material “Peroxyacetic acid, distilled, stabilized, not more than 41%” to include a Note 1, that a ““Corrosive” subsidiary risk placard is required.” The proposed adoption of this requirement is consistent with the requirements in the UN Model Regulations.

Section 173.231

Currently, the § 172.101 HMT Column (8B) and (8C) packaging authorization for Ammonium nitrate emulsion, suspension, or gel, UN3375, directs the reader to § 173.214 which requires that packagings and method of shipment must be approved by the Associate Administrator prior to the first shipment. In this NPRM, PHMSA is proposing to add a new § 173.231 titled “Ammonium nitrate emulsion, suspension or gel” and assigned this section to UN3375 to authorize and prescribe the use of packagings for this material. The requirements of the proposed new section are consistent with the requirements in the UN Model Regulations.

Section 173.301b

In this NPRM, PHMSA is proposing to revise paragraph (c) relating to pressure receptacle valve requirements to include that a valve manufactured on or before December 31, 2008, conforming to the requirements in ISO 10297:1999 is authorized. This proposed revision is consistent with the requirements in the UN Model Regulations.

Section 173.302

In this NPRM, PHMSA is proposing to adopt the new UN Model Regulation requirements for the transportation of adsorbed gases in cylinders. This section specifies requirements for the filling of cylinders with non-liquefied (permanent) compressed gases. PHMSA is proposing to amend the title of this section and to amend paragraph (a) to include and specify requirements for the transportation of adsorbed gases.

Section 172.302c

In this NPRM, PHMSA is proposing to add a new § 173.302c to adopt the new authorization in the UN Model Regulations for the transportation of adsorbed gases in UN pressure receptacles. The proposed adoption of these requirements into this new section is consistent with the requirements in the UN Model Regulations.

Section 173.307

Section 173.307 provides exceptions from the regulations for compressed gases. In this NPRM, PHMSA is proposing to revise paragraph (a)(5) relating to manufactured articles or apparatuses to clarify that the exception for manufactured articles does not include lamps. The exceptions for lamps are contained in the proposed new § 173.11 relating to exceptions for shipment of lamps containing hazardous materials. Also, we are proposing to revise paragraph (a)(6) relating to light bulbs to clarify that the exceptions does not apply to lamps as described in the proposed new § 173.11 relating to exceptions for shipment of lamps containing hazardous materials.

Section 173.309

Section 173.309 prescribes requirements for fire extinguishers. In this NPRM, we are proposing to add a new introductory paragraph describing fire extinguisher types authorized for transport in accordance with this section and covered by the HMT entry “UN1044, Fire extinguishers.”

Section 173.403

Consistent with the UN Model regulations, in this NPRM, PHMSA is proposing to revise two definitions in § 173.403 relating to the transportation of Class 7 (Radioactive Materials). “Exclusive Use” is being revised to clarify that it also applies to the shipment of the load and that exclusive use only applies when compliance is required by the regulations. “Freight Container” is being revised to eliminate the requirement that a “small freight container” has one outer dimension less than 1.4 m (4.9 feet).

Section 173.420

Section 173.420 prescribes the transport conditions for Uranium hexafluoride. In this NPRM PHMSA is proposing to amend paragraph (d) which provides the requirements for shipments of uranium hexafluoride in quantities less than 0.1 kg to incorporate changes made by the IAEA in SSR-6 that were subsequently incorporated in the UN Model Regulations. In this NPRM PHMSA is proposing to amend this paragraph to note that fissile-excepted shipments less than 0.1 kg may be offered under UN3507. PHMSA is proposing to amend the requirements for these shipments to align with IAEA SSR-6 requirements, while maintaining general packaging requirements from §§ 173.24 and 173.24a.

U.S. Coast Guard

U.S. Department of Energy

U.S. Department of Interior

2. 49 U.S.C. 5120(b) authorizes the Secretary of Transportation to ensure that, to the extent practicable, regulations governing the transportation of hazardous materials in commerce are consistent with standards adopted by international authorities. This rule proposes to amend the HMR to maintain alignment with international standards by incorporating various amendments to facilitate the transport of hazardous material in international commerce. To this end, as discussed in detail above, PHMSA proposes to incorporate changes into the HMR based on the 18th Revised Edition of the UN Model Regulations, Amendment 37-14 to the IMDG Code, and the 2015-2016 Edition of the ICAO TI, which become effective January 1, 2015. The large volume of hazardous materials transported in international commerce warrants the harmonization of domestic and international requirements to the greatest extent possible.

B. Executive Orders 12866 and 13563 and DOT Regulatory Policies and Procedures

This notice is not considered a significant regulatory action under section 3(f) of Executive Order 12866 (“Regulatory Planning and Review”) and, therefore, was not reviewed by the Office of Management and Budget. This notice is not considered a significant rule under the Regulatory Policies and Procedures of the Department of Transportation (44 FR 11034). Additionally, E.O. 13563 (“Improving Regulation and Regulatory Review”) supplements and reaffirms E.O. 12866, stressing that, to the extent permitted by law, an agency rulemaking action must be based on benefits that justify its costs, impose the least burden, consider cumulative burdens, maximize benefits, use performance objectives, and assess available alternatives.

Benefits To Harmonization

In an earlier regulatory evaluation,¹
we estimated a proxy for benefits of harmonization of the HMR with international standards of $62 million. More specifically, this $62 million was estimated by multiplying a hazard communication cost per dollar of hazardous materials output—$0.001—by the value of hazardous materials involved in international trade, as estimated by the proportion of trade (the total of gross imports and gross exports) in the fuels and lubricants, chemicals, and medicinal/dental/pharmaceutical products industries ($498 billion in 2010)²
that are hazardous products (i.e., 12.4 percent).³

^[4]

For estimating benefits of this Amendment 1, we follow a nearly identical approach (acknowledging there is an inherent imprecision of benefits here), updating data and assumptions where possible. 2012 Commodity Flow Survey data on hazardous materials are not yet available as of the date of this regulatory evaluation.

However, the 12.4 percent proportion (of total shipment values classed as hazardous materials) estimated in the earlier regulatory evaluation may have had a high-side bias due to the variety of different classes of products classified as hazardous. In actuality, the percentage of shipments properly classified as hazardous is likely lower, particularly for medicinal/dental/pharmaceuticals. Here, we assume a slightly lower proportion to arrive at an estimate of benefits of 10 percent.

We update our estimate of value of hazardous materials involved in international trade by using U.S. Trade in Goods seasonally adjusted, Census-based total gross imports and gross exports in the fuels and lubricants, chemicals, and medicinal/dental/pharmaceutical products industries for the fourth quarter of 2013, the most recent quarter available—

• Gross imports: $134 billion (rounded)

○ Fuels and lubricants: $94.744 billion

○ Chemicals: $18.637 billion

○ Medicinal/dental/pharmaceutical products: $20.613 billion

• Gross exports: $85.8 billion (rounded)

○ Fuels and lubricants: $44.301 billion

○ Chemicals: $30.089 billion

○ Medicinal/dental/pharmaceutical products: $11.416 billion

• Gross imports plus gross exports: $219.8 billion
  ^[5]


Multiplying the quarterly estimate of $219.8 billion by 4 gives an annual estimate of gross imports plus gross exports in the three industries of $879.2 billion. Multiplying this figure by 10 percent (the estimated proportion of annual trade in these three industries that are hazardous products) by the average hazard communication cost per dollar of hazardous materials produced in the United States ($0.001) results in an estimate of benefits from Amendment 1 of $87.9 million (rounded) annually.

If U.S. regulations are not harmonized with international standards, we estimate that it will cost U.S. companies an additional $87.9 million per year to comply with both the HMR and the international standards. Harmonizing the HMR with the international standards, however, will avert these $87.9 million in additional costs, and these averted costs are therefore considered the primary benefit attributable to this rulemaking.

Costs of Harmonization. The primary cost of updating references in the U.S. HMR (to incorporate the most recent international hazardous material standards) is the purchase of updated copies of the international standards being incorporated by reference in the HMR. These costs will be borne by offerors and transporters of hazmat if this rulemaking were finalized.

It is unknown how many individuals and firms involved in shipping hazmat will purchase copies of these international standards as a result of finalizing this rulemaking. We take a conservative approach to estimating such a figure by using as a proxy the number of shippers, carriers, or other offerors or transporters of hazmat in commerce with a PHMSA registration expiring in 2014. Currently, PHMSA’s registration database indicates 36,731 registrants as of May 20, 2014.
^[6]

Of these, 29,877 (approximately 81 percent) are small businesses as defined by the U.S. Small Business Administration. Further, 31,598 registrants (approximately 86 percent) indicated that they offer or transport hazmat solely by highway method.

If we assume (for conservative estimation purposes) that all registrants will purchase copies of all publications, this indicates an estimated cost of this amendment of $56.68 million (rounded, $1,543 cost of all publications * 36,731 registrants). (In reality, all of the ISO standards incorporated will not be purchased by the majority of shippers and carriers, and will likely only impact a small subset of the regulated community. Further, it is likely that many companies will purchase multiple copies of the IMDG Code and ICAO TI, rather than only one copy. We do not believe we have sufficient data to estimate the precise number of registrants. However, we use one copy per registrant as a reasonably conservative estimate on costs of the proposed rulemaking.)

However, further assuming that those who indicated that they offer or transport in commerce hazmat only via highway, two publications included in the $1,543 cost will not apply to such registrants (ICAO TI [for air] and IMDG Code [by vessel]). Therefore, costs for the 31,598 highway-only registrants would total $32.99 million ($1,543—$155 [ICAO TI]—$344 [IMDG Code] * 31,598 highway-only registrants). Conservatively (i.e., overestimating costs and underestimating benefits) assuming all other registrants (while acknowledging that, in fact, some will purchase all standards copies and some will purchase none) will purchase updated copies of all standards publications listed here indicates a total cost of this Amendment 1 of $40.91 million, incurred once ($32.99 million + $1,543 * [36,731 total registrants—31,598 highway-only registrants], rounded).

Net Benefit. Based on the discussions of benefits and costs provided above, the estimated net benefit associated with the international harmonization final rule (2137-AF05) is $47 million in the first year after publication and $87.9 million in the second year after publication. Please see the complete regulatory analysis, a copy of which has been placed in the docket for this rulemaking, for a more detailed analysis of the costs and benefits of this proposed rule.

C. Executive Order 13132

This proposed rule has been analyzed in accordance with the principles and criteria contained in Executive Order 13132 (“Federalism”). This proposed rule preempts State, local, and Indian tribe requirements but does not propose any regulation that has substantial direct effects on the States, the relationship between the national government and the States, or the distribution of power and responsibilities among the various levels of government. Therefore, the consultation and funding requirements of Executive Order 13132 do not apply.

The Federal hazardous material transportation law, 49 U.S.C. 5101-5128, contains an express preemption provision (49 U.S.C. 5125(b)) that preempts State, local, and Indian tribe requirements on certain covered subjects, as follows:

• The designation, description, and classification of hazardous material;
• The packing, repacking, handling, labeling, marking, and placarding of hazardous material;
• The preparation, execution, and use of shipping documents related to hazardous material and requirements related to the number, contents, and placement of those documents;
• The written notification, recording, and reporting of the unintentional release in transportation of hazardous material; and
• The design, manufacture, fabrication, inspection, marking, maintenance, recondition, repair, or testing of a packaging or container represented, marked, certified, or sold as qualified for use in transporting hazardous material in commerce.

This proposed rule addresses the covered subject items above and preempts State, local, and Indian tribe requirements not meeting the “substantively the same” standard. This proposed rule is necessary to incorporate changes adopted in international standards, effective January 1, 2015. If the changes in this proposed rule are not adopted in the HMR, U.S. companies, including numerous small entities competing in foreign markets, would be at an economic disadvantage. These companies would be forced to comply with a dual system of regulations. The changes in this proposed rulemaking are intended to avoid this result. Federal hazardous materials transportation law provides at 49 U.S.C. 5125(b)(2) that, if DOT issues a regulation concerning any of the covered subjects, DOT must determine and publish in the Federal Register the effective date of Federal preemption. The effective date may not be earlier than the 90th day following the date of issuance of the final rule and not later than two years after the date of issuance. PHMSA proposes the effective date of Federal preemption be 90 days from publication of a final rule in this matter.

D. Executive Order 13175

This proposed rule was analyzed in accordance with the principles and criteria contained in Executive Order 13175 (“Consultation and Coordination with Indian Tribal Governments”). Because this proposed rule does not have tribal implications, does not impose substantial direct compliance costs, and is required by statute, the funding and consultation requirements of Executive Order 13175 do not apply.

E. Regulatory Flexibility Act, Executive Order 13272, and DOT Procedures and Policies

The Regulatory Flexibility Act (5 U.S.C. 601 et seq.) requires an agency to review regulations to assess their impact on small entities, unless the agency determines that a rule is not expected to have a significant impact on a substantial number of small entities. This proposed rule facilitates the transportation of hazardous materials in international commerce by providing consistency with international standards. This proposed rule applies to offerors and carriers of hazardous materials, some of whom are small entities, such as chemical manufacturers, users and suppliers, packaging manufacturers, distributors, and training companies. As discussed above, under Executive Order 12866, the majority of amendments in this proposed rule should result in cost savings and ease the regulatory compliance burden for shippers engaged in domestic and international commerce, including trans-border shipments within North America.

Many companies will realize economic benefits as a result of these amendments. Additionally, the changes effected by this NPRM will relieve U.S. companies, including small entities competing in foreign markets, from the burden of complying with a dual system of regulations. Therefore, we certify that these amendments will not, if promulgated, have a significant economic impact on a substantial number of small entities.

This proposed rule has been developed in accordance with Executive Order 13272 (“Proper Consideration of Small Entities in Agency Rulemaking”) and DOT’s procedures and policies to promote compliance with the Regulatory Flexibility Act to ensure that potential impacts of draft rules on small entities are properly considered.

F. Paperwork Reduction Act

PHMSA currently has approved information collection under Office of Management and Budget (OMB) Control Number 2137-0034, “Hazardous Materials Shipping Papers and Emergency Response Information.” We anticipate that this proposed rule will result in an increase in the annual information collection burden of this information collection due to an increase in the number of shipping papers prepared for packages containing batteries that exceeds the number or quantity (mass) limits in the table shown in § 173.185(c)(4), but containing no more than 2.5 kg of lithium metal cells or batteries or 10 kg of lithium ion cells or batteries per package. Shipments utilizing this allowance currently provide alternative documentation containing the name and address of the offeror and consignee, the UN number, an indication of compliance with this paragraph (c)(4) (or the applicable ICAO Packing Instruction), and the number of packages and the gross mass of each package.

This rulemaking identifies a revised information collection that PHMSA will submit to OMB for approval based on the requirements in this NPRM. PHMSA has developed burden estimates to reflect changes in this NPRM, and estimates the information collection and recordkeeping burden in this rule are as follows:

OMB Control Number: 2137-0034.

Annual Increase in Number of Respondents: 150.

Annual Increase in Annual Number of Responses: 13,167.

Annual Increase in Annual Burden Hours: 219.

Annual Increase in Annual Burden Costs:$4,380.

Under the Paperwork Reduction Act of 1995, no person is required to respond to an information collection unless it has been approved by OMB and displays a valid OMB control number. Section 1320.8(d), title 5, Code of Federal Regulations requires that PHMSA provide interested members of the public and affected agencies an opportunity to comment on information and recordkeeping requests. PHMSA specifically requests comments on the information collection and recordkeeping burdens associated with developing, implementing, and maintaining these proposed requirements. Address written comments to the Dockets Unit as identified in the ADDRESSES section of this rulemaking. We must receive comments regarding information collection burdens prior to the close of the comment period identified in the DATES section of this rulemaking. In addition, you may submit comments specifically related to the information collection burden to the PHMSA Desk Officer, Office of Management and Budget, at fax number 202-395-6974. Requests for a copy of this information collection should be directed to Steven Andrews or T. Glenn Foster, Standards and Rulemaking Division (PHH-10), Pipeline and Hazardous Materials Safety Administration, 1200 New Jersey Avenue SE., Washington, DC 20590-0001. If these proposed requirements are adopted in a final rule, PHMSA will submit the revised information collection and recordkeeping requirements to OMB for approval.

G. Regulation Identifier Number (RIN)

A regulation identifier number (RIN) is assigned to each regulatory action listed in the Unified Agenda of Federal Regulations. The Regulatory Information Service Center publishes the Unified Agenda in April and October of each year. The RIN contained in the heading of this document can be used to cross-reference this action with the Unified Agenda.

H. Unfunded Mandates Reform Act

This proposed rule does not impose unfunded mandates under the Unfunded Mandates Reform Act of 1995. It does not result in costs of $141.3 million or more, adjusted for inflation, to either State, local, or tribal governments, in the aggregate, or to the private sector in any one year, and is the least burdensome alternative that achieves the objective of the rule.

I. Environmental Assessment

The National Environmental Policy Act, 42 U.S.C. 4321-4375, requires that federal agencies analyze proposed actions to determine whether the action will have a significant impact on the human environment. The Council on Environmental Quality (CEQ) regulations require federal agencies to conduct an environmental review considering: (1) The need for the proposed action; (2) alternatives to the proposed action; (3) probable environmental impacts of the proposed action and alternatives; and (4) the agencies and persons consulted during the consideration process. 40 CFR 1508.9(b).

Description of Action

Docket No. PHMSA-2013-0260 (HM-215M), NPRM. The transportation of hazardous materials in commerce is subject to the HMR, issued under authority of Federal hazardous materials transportation law, codified at 49 U.S.C. 5001 et seq. To facilitate the safe and efficient transportation of hazardous materials in international commerce, the HMR provides that both domestic and international shipments of hazardous materials may be offered for transportation and transported under provisions of the international regulations.

Purpose and Need

This action is necessary to integrate into the HMR recent changes to the International Maritime Dangerous Goods Code (IMDG Code), the International Civil Aviation Organization’s Technical Instructions for the Safe Transport of Dangerous Goods by Air (ICAO TI), and the United Nations Recommendations on the Transport of Dangerous Goods—Model Regulations (UN Model Regulations) effective January 1, 2015. If the changes in this proposed rule are not adopted in the HMR by this effective date, US companies, including numerous small entities competing in foreign markets, would be at an economic disadvantage. These companies would be forced to comply with a dual system of transport regulations that could result in shippers and carriers segmenting domestic and international operations to accommodate differing requirements. The changes to the HMR contained in this proposed rulemaking are intended to avoid this result.

The intended effect of this action is to align the HMR with international hazardous material transport standards and requirements to the extent practicable in accordance with Federal Hazardous Materials transportation law (49 U.S.C. 5210). When considering the adoption of international hazardous material standards under the HMR, PHMSA reviews and evaluates each amendment on its own merit, on the basis of its overall impact on transportation safety, and the economic implications associated with its adoption into the HMR. Our goal is to harmonize without diminishing the level of safety currently provided by the HMR and without imposing undue burdens on the regulated public.

In this NPRM, PHMSA is proposing to amend the Hazardous Materials Regulations to maintain alignment with international standards by incorporating various amendments, including changes to proper shipping names, hazard classes, packing groups, special provisions, packaging authorizations, air transport quantity limitations, and vessel stowage requirements. These revisions are necessary to harmonize and align the HMR with recent amendments adopted in the UN Model Regulations, IMDG Code, and the ICAO TI. The amendments proposed in this notice are intended to facilitate the safe and efficient transportation of hazardous materials in international commerce, provide clarity to encourage and increase regulatory compliance, and improve the efficacy of emergency response in the event of a hazardous materials incident.

Alternatives

In proposing this rulemaking, PHMSA is considering the following alternatives:

No Action Alternative:

If PHMSA chose this alternative, it would not proceed with any rulemaking on this subject and the current regulatory standards would remain in effect.

Preferred Alternative:

This alternative is the current proposal as it appears in this Notice of Proposed Rulemaking (NPRM), applying to the transportation of hazardous materials by various transport modes (highway, rail, vessel and aircraft). The proposed amendments included in this alternative are more fully addressed in the preamble and regulatory text sections of this NPRM. However, they generally include: (1) Updates to references to various international hazardous materials transport standards; (2) Amendments to the hazardous materials table to add, revise, or remove certain proper shipping names, packing groups, special provisions, packaging authorizations, bulk packaging requirements and vessel stowage requirements; (3) Amendments to add and delete various substances to the list of marine pollutants in Appendix B to § 172.101; (4) Changes throughout the Part 173 packaging requirements to authorize more flexibility when choosing packages for hazardous materials; (5) An exception from the HMR for marine pollutants up to 5 liters (1.3 gallons) for liquids or 5 kg (11 pounds) for solids when these materials are packaged in accordance with the general packaging requirements of §§ 173.24 and 173.24a; (6) Minimum sizes for the OVERPACK and SALVAGE markings; and; (7) Revisions and additions to vessel stowage codes listed in column 10B of the HMT and segregation requirements in § 176.83 consistent with the IMDG Code.

No Action Alternative

If PHMSA were to select the No Action Alternative, current regulations would remain in place, and no new provisions would be added. However, efficiencies gained through harmonization in updates to transport standards, lists of regulated substances, definitions, packagings, stowage requirements/codes, flexibilities allowed, enhanced markings, segregation requirements, etc., would not be realized. Foregone efficiencies in the No Action Alternative include freeing up limited resources to concentrate on vessel transport hazard communication (hazcom) issues of potentially much greater environmental impact.

Additionally, the Preferred Alternative encompasses enhanced and clarified regulatory requirements, which would result in increased compliance and fewer environmental and safety incidents. Not adopting the proposed environmental and safety requirements in the NPRM under the No Action Alternative would result in a lost opportunity for reducing environmental and safety-related incidents.

Greenhouse gas emissions would remain the same under the No Action Alternative.

Preferred Alternative

If PHMSA selects the provisions as proposed in this NPRM, we believe that safety and environmental risks would be reduced and that protections to human health and environmental resources would be increased. Potential environmental impacts of each proposed amendment in the preferred alternative are discussed below:

1. Propose updates to references to various international hazardous materials transport standards, including the 2015-2016 Edition of the ICAO TI; Amendment 37-14 to the IMDG Code; the 18th Revised Edition of the UN Model Regulations; Amendment 2 to the 5th revised edition of the UN Manual of Tests and Criteria; incorporation by reference of the Canadian Transportation of Dangerous Goods Regulations to include Amendment 11 (SOR/2011-239) October 27, 2011 and; adding two new references standards and update four other references to standards applicable to the manufacture, use, and requalification of pressure vessels published by the International Organization for Standardization:

The HMR authorize shipments prepared in accordance with the ICAO TI and transported by motor vehicle either before or after being transported by aircraft. Similarly, the HMR authorize shipments prepared in accordance with the IMDG Code if all or part of the transportation is by vessel. The authorizations to use the ICAO TI and the IMDG code are subject to certain conditions and limitations outlined in part 171 subpart C. PHMSA believes that this proposed amendment, which will increase standardization and consistency of regulations, will result in greater protection of human health and the environment. Consistency between U.S. and international regulations enhances the safety and environmental protection of international hazardous materials transportation through better understanding of the regulations, an increased level of industry compliance, the smooth flow of hazardous materials from their points of origin to their points of destination, and consistent emergency response in the event of a hazardous materials incident.

Enhanced environmental protection will also be achieved through more targeted and effective training. This proposed amendment will eliminate inconsistent hazardous materials regulations, which hamper compliance training efforts. For ease of compliance with appropriate regulations, air and vessel carriers engaged in the transportation of hazardous materials generally elect to comply with the ICAO TI and IMDG Code as appropriate. By maintaining consistency between these international regulations and the HMR, shippers and carriers are able to train their hazmat employees in a single set of requirements for classification, packaging, hazard communication, handling, stowage, etc., thereby minimizing the possibility of improperly preparing and transporting a shipment of hazardous materials because of differences between domestic and international regulations.

Greenhouse gas emissions would remain the same under this proposed amendment.

2. Propose amendments to the HMT to add, revise, or remove certain proper shipping names, packing groups, special provisions, packaging authorizations, bulk packaging requirements and vessel stowage requirements:

PHMSA believes that this proposed amendment, which will increase standardization and consistency of regulations, will result in greater protection of human health and the environment. Consistency between US and international regulations enhances the safety and environmental protection of international hazardous materials transportation through better understanding of the regulations, an increased level of industry compliance, the smooth flow of hazardous materials from their points of origin to their points of destination, and consistent emergency response in the event of a hazardous materials incident. New and revised entries to the HMT reflect emerging technologies, and a need to better describe or differentiate between existing entries. These proposed changes mirror changes in the Dangerous Goods list of The 18th Revised Edition of the UN Model Regulations, the 2015-2016 Edition of the ICAO TI and the 37-14 amendments to the IMDG Code. It is extremely important for the domestic HMR to mirror the UN Model Regulations, the ICAO TI, and the IMDG Code with respect to the entries in the HMT to ensure consistent naming conventions across modes and international borders.

Enhanced environmental protection will also be achieved through more targeted and effective training. This proposed amendment will eliminate inconsistent hazardous materials regulations, which hamper compliance training efforts. For ease of compliance with appropriate regulations, international carriers engaged in the transportation of hazardous materials by vessel generally elect to comply with the IMDG Code. By maintaining consistency between these international regulations and the HMR, shippers and carriers are able to train their hazmat employees in a single set of requirements for classification, packaging, hazard communication, handling, stowage, etc., thereby minimizing the possibility of improperly preparing and transporting a shipment of hazardous materials because of differences between domestic and international regulations.

The packing group assignment reflects a degree of danger associated with a particular material and identifies appropriate packaging. However, assignment of a packing group is not appropriate in all cases (e.g. explosives, gases, radioactive material). In such cases the packing group does not indicate a degree of danger and the packaging requirements for those materials are specified in the appropriate section in part 173. Similarly for articles, the packing group only reflects the degree of the danger posed by the hazardous component, but may not reflect danger of the article itself, which may be substantially reduced or changed when compared to shipping the hazardous component alone. Currently and without specific rationale, some articles are assigned packing groups while others are not. The inconsistent application of packing groups to articles can create problems for trainers when trying to explain regulatory structure to students. This proposed change provides a level of consistency for all articles specifically listed in the HMT, without diminishing environmental protection and safety.

For adsorbed gases, PHMSA proposes adding into the HMR a definition, HMT entries, authorized packagings and safety requirements including but not limited to quantity limitations and filling limits. PHMSA believes that this proposed amendment will result in greater protection of human health and the environment by facilitating the safe and efficient transport of gases adsorbed onto a porous media within cylinders. This technology allows the cylinder to be filled and transported with gas at sub-atmospheric pressure. Sub-atmospheric transport of gas minimizes potential leaks of gas during transportation, thus providing significant safety and environmental improvements over traditional high-pressure cylinders. This method of transporting gas is a proven safe method authorized through a PHMSA special permit for over ten years and recently adopted into the UN Model Regulations, the ICAO TI and the IMDG Code.

Greenhouse gas emissions would remain the same under this proposed amendment.

3. Propose additions and deletions of various substances to/from the list of Marine Pollutants in HMR, Appendix B to 172.101:

As for the above amendments, PHMSA believes that this proposed amendment, which will increase standardization and consistency of regulations, will result in greater protection of human health and the environment. Consistency between US and international regulations enhances the safety and environmental protection of international hazardous materials transportation through better understanding of the regulations, an increased level of industry compliance, the smooth flow of hazardous materials from their points of origin to their points of destination, and consistent emergency response in the event of a hazardous materials incident. The proposed additions and deletions are based on the criteria contained in the IMDG code for substances classified as toxic to the aquatic environment. The HMR maintain a list as the basis for regulating substances toxic to the aquatic environment and allow use of the criteria in the IMDG Code if a listed material does not meet the criteria for a marine pollutant. PHMSA periodically updates its list based on changes to the IMDG code and evaluation of listed materials against the IMDG code criteria. Amending the marine pollutant list will facilitate consistent communication of the presence of marine pollutants and facilitate safe and efficient transportation without imposing significant burden associated with characterizing mixtures as marine pollutants.

Also similar to the above amendments, enhanced environmental protection will also be achieved through more targeted and effective training. This proposed amendment will eliminate inconsistent hazardous materials regulations, which hamper compliance training efforts. For ease of compliance with appropriate regulations, international carriers engaged in the transportation of hazardous materials by vessel generally elect to comply with the IMDG Code. By maintaining consistency between these international regulations and the HMR, shippers and carriers are able to train their hazmat employees in a single set of requirements for classification, packaging, hazard communication, handling, stowage, etc., thereby minimizing the possibility of improperly preparing and transporting a shipment of hazardous materials because of differences between domestic and international regulations.

Greenhouse gas emissions would remain the same under this proposed amendment.

4. Propose adopting changes throughout the HMR Part 173 packaging requirements to authorize more flexibility when choosing packages for hazardous materials:

The proposed changes would adopt manufacturing and performance standards for small gas pressure receptacles without a relief device, clarify the use of the HMT entry “fire extinguisher”, authorize the use of large salvage packagings and provide a list of authorized packagings for ammonium nitrate emulsions. As for the above amendments, PHMSA believes that these proposed amendments, which will increase standardization and consistency of regulations, will result in greater protection of human health and the environment. Consistency between US and international regulations enhances the safety and environmental protection of international hazardous materials transportation through better understanding of the regulations, an increased level of industry compliance, the smooth flow of hazardous materials from their points of origin to their points of destination, and consistent emergency response in the event of a hazardous materials incident. PHMSA proposes to adopt changes throughout the Part 173 packaging requirements to authorize more flexibility when choosing packages for hazardous materials. This action is consistent with amendments adopted into the UN Model Regulations.

These amendments permit additional flexibility for authorized packages without compromising environmental protection or safety. Manufacturing and performance standards for small gas pressure receptacles ensure a safe packaging that is capable of retaining its contents without being overly prescriptive. The proposed clarification for fire extinguishers increases the transparency of the regulations, which will in turn result in increased compliance, reduced incidents of undeclared or mis-declared hazardous material and enhanced environmental protection and safety. Increased flexibility will also add to environmental protection by increasing the ease of regulatory compliance.

Also similar to the above amendments, enhanced environmental protection will be achieved through more targeted and effective training. This proposed amendment will eliminate inconsistent hazardous materials regulations, which hamper compliance training efforts. By maintaining consistency between the UN Model Regulations and the HMR, shippers and carriers are able to train their hazmat employees in a single set of requirements for classification, packaging, hazard communication, handling, stowage, etc., thereby minimizing the possibility of improperly preparing and transporting a shipment of hazardous materials because of differences between domestic and international regulations.

Greenhouse gas emissions would remain the same under this proposed amendment.

5. Proposed exception from the HMR for marine pollutants up to 5 liters (1.3 gallons) for liquids or 5 kg (11 lbs.) for solids when these materials are packaged in accordance with the general packaging requirements of §§ 173.24 and 173.24a:

PHMSA believes that this proposed amendment would provide for a slight net increase in environmental protection and safety by reducing confusion and simplifying multi-modal transit hazardous material transportation requirements. Currently, packages containing less than 5 liters (1.3 gallons) for liquids or 5 kg (11 lbs.) of material containing marine pollutants are subject to additional requirements such as shipping papers, Class 9 labelling and UN packaging when offered for transport by air or vessel in accordance with the ICAO TI or the IMDG Code. However, these same materials would not be subject to the HMR when transported by motor vehicle, rail car or aircraft in the U.S. The presence of these labels in one mode of transport can cause confusion in the U.S. supply chain.

The proposed amendment would exempt from the HMR small packages of hazardous material that are regulated only because of the presence of one or more marine pollutants. Materials in these quantities pose a low risk in transportation. In addition, these low quantities of materials present even lower risks in transportation because they often contain low concentrations of marine pollutant constituents. Lastly, risks of incidents are very low. In the past 10 years, in tens of thousands of vessel shipments, PHMSA’s data contains only one record of marine pollutant released on a vessel that caused environmental damage. In this incident, the material was packaged in a 55-gallon drum and would not be impacted by the proposed amendment, since the package would still be required to display the marine pollutant mark and the shipping documents would still have to communicate the presence of a marine pollutant. By reducing the hazard communication (hazcom) burdens for lower risk commodities, industry, shippers, and transporters can focus hazard communication resources on areas with potentially greater environmental and safety consequences.

The proposed action is consistent with recent revisions to the IMDG Code. PHMSA believes that this proposed amendment will increase standardization and consistency of regulations, may also result in greater protection of human health and the environment. Consistency between U.S. and international regulations enhances the safety and environmental protection of international hazardous materials transportation through better understanding of the regulations, an increased level of industry compliance, the smooth flow of hazardous materials from their points of origin to their points of destination, and consistent emergency response in the event of a hazardous materials incident. Excepting these quantities of marine pollutants from the HMR will facilitate consistent communication of the presence of marine pollutants and facilitate safe and efficient transportation without imposing significant burden associated with characterizing mixtures as marine pollutants.

Also similar to the above amendments, enhanced environmental protection will also be achieved through more targeted and effective training. This proposed amendment will eliminate inconsistent hazardous materials regulations, which hamper compliance training efforts. For ease of compliance with appropriate regulations, international carriers engaged in the transportation of hazardous materials by vessel generally elect to comply with the IMDG Code. By maintaining consistency between these international regulations and the HMR, shippers and carriers are able to train their hazmat employees in a single set of requirements for classification, packaging, hazard communication, handling, stowage, etc., thereby minimizing the possibility of improperly preparing and transporting a shipment of hazardous materials because of differences between domestic and international regulations.

Greenhouse gas emissions would remain the same under this proposed amendment.

6. Proposed amendments to add minimum sizes for the OVERPACK and SALVAGE markings. These markings would be characters at least 12 mm (.47 inches) high:

PHMSA believes that this proposed amendment, which will provide for enhanced hazard communication, will result in greater protection of human health and the environment. An overpack is an enclosure to provide protection or convenience of handling for one or more packages such as pallets and crates. A salvage package is used to contain a damaged, leaking or non-conforming package. The HMR require these packages to be marked OVERPACK or SALVAGE, as appropriate. This communicates the nature of these specialized packaging configurations to package handlers and emergency responders. However, because there is currently no minimum size requirement for these marks, this information is not always readily visible. This proposed amendment would ensure that these hazard markings are visible, thus resulting in decreased incidents with impacts to the environment and safety.

Greenhouse gas emissions would remain the same under this proposed amendment.

7. Proposed amendments to revise and add vessel stowage codes listed in column 10B of the HMT and segregation requirements in HMR § 176.83 consistent with the IMDG Code. These changes are designed to harmonize with the IMDG Code and would provide additional guidance on the loading and stowage of various materials. Additionally, proposed amendments to increase the required segregation distances between Division 4.3 dangerous when wet material (i.e. materials liable to give off a flammable or toxic gas in contact with water) and Class 3 flammable liquids and Division 2.1 flammable gases:

As discussed for previous amendments herein, PHMSA believes that this proposed amendment, which will increase standardization and consistency of regulations, will result in greater protection of human health and the environment. Consistency between U.S. and international regulations enhances the safety and environmental protection of international hazardous materials transportation through better understanding of the regulations, an increased level of industry compliance, the smooth flow of hazardous materials from their points of origin to their points of destination, and consistent emergency response in the event of a hazardous materials incident. New and revised entries to the HMT reflect emerging technologies, and a need to better describe or differentiate between existing entries. These proposed changes mirror the IMDG Code. It is extremely important for the domestic HMR and HMT to mirror the IMDG Code to ensure consistent naming conventions across modes and international borders.

Enhanced environmental protection will also be achieved through more targeted and effective training. This proposed amendment will eliminate inconsistent hazardous materials regulations, which hamper compliance training efforts. For ease of compliance with appropriate regulations, international carriers engaged in the transportation of hazardous materials by vessel generally elect to comply with the IMDG Code. By maintaining consistency between these international regulations and the HMR, shippers and carriers are able to train their hazmat employees in a single set of requirements for classification, packaging, hazard communication, handling, stowage, etc., thereby minimizing the possibility of improperly preparing and transporting a shipment of hazardous materials because of differences between domestic and international regulations.

PHMSA also believes that this group of amendments will increase environmental protection and safety through its increased segregation distance requirements and enhanced guidance, which will better prevent materials from contacting each other and/or water in transportation. Increased segregation distances prevent the mixing of incompatible material and the subsequent evolution of flammable or toxic gases, along with attendant fires and explosions. Together, stowage and segregation help manage the risks associated with the transport of hazardous materials by water. While the risk associated with the transport of these materials is relatively low, these measures would further reduce that risk and prevent the spread of a fire between flammable materials and materials that react dangerously with water.

Greenhouse gas emissions would remain the same under this proposed amendment.

Agencies Consulted:

This NPRM represents PHMSA’s first action in the U.S. for this program area. PHMSA has coordinated with the U.S. Federal Aviation Administration and the U.S. Coast Guard, in the development of this proposed rule. PHMSA will consider the views expressed in comments to the NPRM submitted by members of the public, state and local governments, and industry.

Conclusion:

The provisions of this proposed rule build on current regulatory requirements to enhance the transportation safety and security of shipments of hazardous materials transported by highway, rail, aircraft and vessel, thereby reducing the risks of an accidental or intentional release of hazardous materials and consequent environmental damage. PHMSA believes the net environmental impact will be positive. PHMSA believes that there are no significant environmental impacts associated with this proposed rule.

PHMSA welcomes any views, data, or information related to environmental impacts that may result if the proposed requirements are adopted, as well as possible alternatives and their environmental impacts.

J. Privacy Act

Anyone is able to search the electronic form of any written communications and comments received into any of our dockets by the name of the individual submitting the document (or signing the document, if submitted on behalf of an association, business, labor union, etc.). You may review DOT’s complete Privacy Act Statement in the Federal Register published on April 11, 2000 (65 FR 19477) or you may visit http://www.dot.gov/privacy.html
.

K. Executive Order 13609 and International Trade Analysis

Under E.O. 13609, agencies must consider whether the impacts associated with significant variations between domestic and international regulatory approaches are unnecessary or may impair the ability of American business to export and compete internationally. In meeting shared challenges involving health, safety, labor, security, environmental, and other issues, international regulatory cooperation can identify approaches that are at least as protective as those that are or would be adopted in the absence of such cooperation. International regulatory cooperation can also reduce, eliminate, or prevent unnecessary differences in regulatory requirements.

Similarly, the Trade Agreements Act of 1979 (96), as amended by the Uruguay Round Agreements Act (103), prohibits Federal agencies from establishing any standards or engaging in related activities that create unnecessary obstacles to the foreign commerce of the United States. For purposes of these requirements, Federal agencies may participate in the establishment of international standards, so long as the standards have a legitimate domestic objective, such as providing for safety, and do not operate to exclude imports that meet this objective. The statute also requires consideration of international standards and, where appropriate, that they be the basis for U.S. standards.

PHMSA participates in the establishment of international standards to protect the safety of the American public, and we have assessed the effects of the proposed rule to ensure that it does not cause unnecessary obstacles to foreign trade. In fact, the rule is designed to facilitate international trade. Accordingly, this rulemaking is consistent with E.O. 13609 and PHMSA’s obligations under the Trade Agreement Act, as amended.

49 CFR Part 171

49 CFR Part 172

49 CFR Part 173

49 CFR Part 175

49 CFR Part 176

49 CFR Part 178

49 CFR Part 180

In consideration of the foregoing, PHMSA proposes to amend 49 CFR Chapter I as follows:

The revisions and additions read as follows:

The additions and revisions read as follows:

The additions and revisions read as follows:
